Cadillac DTS I (2005-2011) (rear seat harness, 18 cm from breakout to rear heated seatback element Wiring diagram
This page shows the only wiring diagram for the component.(rear seat harness, 18 cm from breakout to rear heated seatback element, which is found in the car Cadillac DTS I (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (rear seat harness, 18 cm from breakout to rear heated seatback element (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DK GRN WIRE
GRN WIRE
GRY WIRE
HEATED SEAT BACK CUSHION IND
HEATED SEAT BACK IND
HEATED SEAT BACK SWITCH
HEATED SEAT BACK, CUSHION SWITCH
HEATED SEAT LOW IND HEATED SEAT HIGH IND
HEATED SEAT MEDIUM IND
HEATING ELEMENT
ILLUMINATION
LEFT REAR BACK HEATED SEAT ELEMENT (BEHIND LEFT REAR SEAT BACK)
LEFT REAR CUSHION HEATED SEAT ELEMENT (IN LEFT REAR SEAR SEAT CUSHION)
LEFT REAR HEATED SEAT SWITCH
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/WHT WIRE
NCA WIRE
ORG/ WIRE
ORG/WHT WIRE
PNK WIRE
PNK/BLK WIRE
PNK/YEL WIRE
PPL
PPL/WHT WIRE
RIGHT REAR BACK HEATED SEAT ELEMENT (BEHIND RIGHT REAR SEAT BACK)
RIGHT REAR CUSHION HEATED SEAT ELEMENT (IN RIGHT REAR SEAR SEAT CUSHION)
TAN WIRE
TAN/WHT WIRE
THERMISTOR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Rear heated seats circuit (2 of 2) -> (REAR SEAT HARNESS, 18 CM FROM BREAKOUT TO REAR HEATED SEATBACK ELEMENT
