Cadillac DTS I (2005-2011) passenger seat accent lamp Wiring diagram
This page shows the only wiring diagram for the component.passenger seat accent lamp, which is found in the car Cadillac DTS I (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger seat accent lamp (1 of 1)
ACCENT LAMPS LED CIRCUIT BOARD (IF EQUIPPED)
ASHTRAY LAMP (AUXILIARY)
BLK WIRE
BRN WIRE
CLOCK
DEFOG IND
DK GRN WIRE
DRIVER INFORMATION DISPLAY SWITCH
DRIVER SEAT ACCENT LAMP
GRY WIRE
GRY/BRN WIRE
HAZARD SWITCH
HEADLAMP SWITCH
HEATED SEAT SWITCH
HVAC CONTROL MODULE (CENTER OF DASH)
INFORMATION CENTER TELLTALE ASSEMBLY
LANE DEPARTURE WARNING SENSOR INDICATOR
LEFT I/P ACCENT LAMP
LEFT REAR
LEFT REAR WINDOW SWITCH
ORG/ WIRE
ORG/WHT WIRE
PASSENGER SEAT ACCENT LAMP
PNK WIRE
PNK/BLK WIRE
PPL
PPL/WHT WIRE
RADIO
RIGHT I/P ACCENT LAMP
SEAT LUMBAR SWITCH
SEAT)
W/O LUXURY FRONT BUCKET SEAT
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> PASSENGER SEAT ACCENT LAMP
