Cadillac DTS I (2005-2011) low spd fan serial data + serial data - a/c ref low ref Wiring diagram
This page shows the only wiring diagram for the component.low spd fan serial data + serial data - a/c ref low ref, which is found in the car Cadillac DTS I (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low spd fan serial data + serial data - a/c ref low ref (1 of 1)
1 2 3 4 5 6 7 8 9 10 BATT
4 3 2 1 LOW REF FEED BACK SIG GND MTR SPD CTRL
54 53 RLY CTRL A/C RELAY
A/C CLTCH FUSE 4
A/C CLTCH RELAY 34
A/C COMPRESSOR CLUTCH (LOWER LEFT SIDE OF ENGINE)
A/C REFRIGERANT PRESSURE SENSOR (ON A/C PRESSURE HOSE)
AUXILIARY BLOWER MOTOR (IF EQUIPPED) (UNDER CENTER OF DASH)
AUXILIARY BLOWER MOTOR CONTROL MODULE (IF EQUIPPED) (BEHIND MAIN BLOWER MOTOR)
AUXILIARY HVAC CONTROL MODULE (IF EQUIPPED) (REAR OF CENTER CONSOLE)
BACKLMP CTRL
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (RIGHT REAR OF ENGINE)
FAN 1 FUSE 27
FAN 1 RELAY 33
FAN 2 FUSE 26
FAN 2 RELAY 31
FAN 3 RELAY 32
GRY WIRE
GRY/BLK WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN RUN OR START
HOT W/ PWR/TRN RELAY ENERGIZED
HVAC/IPC IGN 1 FUSE 10
IGN RELAY 36
LEFT COOLING FAN (FRONT OF ENGINE COMPT)
LOW SPD FAN SERIAL DATA + SERIAL DATA - A/C REF LOW REF
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
MTR SPD CTRL FEED BACK SIG SERIAL DATA
ORG/ WIRE
ORG/RED WIRE
ORG/WHT WIRE
OXY SNSR FUSE 6
PNK LOW REF ECT SENS SIG WIRE
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED/DK GRN WIRE
RIGHT COOLING FAN (FRONT OF ENGINE COMPT)
SUNLOAD TWILIGHT SENSOR (TOP CENTER OF DASH)
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> LOW SPD FAN SERIAL DATA + SERIAL DATA - A/C REF LOW REF
