Cadillac DTS I (2005-2011) lo spd gmlan serial data Wiring diagrams

BATTERY BLK WIRE BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH) BRN WIRE COMPUTER DATA LINES SYSTEM CURRENT CURRENT GND SENS SENS LOW REF SIG CURRENT CURRENT SENS SENS LOW REF SIG CURRENT SENS SPLY VOLT DK BLU WIRE DK GRN WIRE FUSIBLE LINK GEN FIELD CYC SIG GEN TURN ON SIG GENERATOR GENERATOR INLINE FUSE GMLAN (ECM) CHARGING IND GRY WIRE HI SPEED GMLAN SERIAL DATA - HOT AT ALL TIMES IGN INSTRUMENT PANEL CLUSTER (IPC) LO SPD GMLAN SERIAL DATA LOGIC ORG/ WIRE ORG/PNK WIRE PASSKEY FUSE 13 PNK WIRE POWER DISTRIBUTION SYSTEM PPL REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RED WIRE RED/BLK WIRE STARTER MOTOR TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT) W/ LIMOUSINE W/O LIMOUSINE WHT WIRE

12 VOLT REF 14 15 RR DR AJAR SW SIG LR DR AJAR SW SIG 15 10 COURTESY LP RLY COURTESY LP SPLY ACCENT LAMPS LED CIRCUIT BOARD (IF EQUIPPED) BATT POS VOLT BCM (CTSY) FUSE 35 BCM (INADV) FUSE 32 BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COURTESY LP CTRL DK BLU WIRE DK GRN WIRE DK GRN/PPL WIRE DK GRN/WHT WIRE DRIVER DOOR SILL PLATE LAMP FRONT PASSENGER DOOR LATCH ASSEMBLY (FRONT PASSENGER'S DOOR.) FRONT PASSENGER DOOR MODULE (FPDM) GMLAN LOW SPEED GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES INSTRUMENT ILLUMINATION CIRCUIT LEFT REAR DOOR COURTESY LAMP LEFT REAR DOOR SILL PLATE LAMP LO SPD GMLAN SERIAL DATA LT BLU WIRE LT BLU/BLK WIRE LT DK LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/WHT WIRE PASSENGER DOOR SILL PLATE LAMP PNK WIRE PPL REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RED WIRE RED/WHT WIRE RF DOOR AJAR SW SIG RF DOOR SW LOW REF RIGHT FRONT DOOR COURTESY LAMP RIGHT REAR DOOR COURTESY LAMP RIGHT REAR DOOR SILL PLATE LAMP TAN WIRE TAN/PNK WIRE TAN/WHT WIRE YEL WIRE

12 VOLT REF 15 10 660 5116 COURTESY LP CTRL COURTESY LP SPLY 15 10 661 5117 COURT LMP CTRL COURT LMP SPLY ACCENT LAMPS LED CIRCUIT BOARD (IF EQUIPPED) BATT POS VOLT BCM (CTSY) FUSE 35 BCM (INADV) FUSE 32 BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH) BRN WIRE COMPUTER DATA LINES SYSTEM COURTESY LP CTRL COURTESY LP RLY COIL CTRL DK BLU WIRE DK BLU/GRY WIRE DK GRN WIRE DK GRN/PPL WIRE DK GRN/WHT WIRE DK LT DRIVER DOOR LATCH ASSEMBLY (REAR OF DRIVER'S DOOR) DRIVER DOOR MODULE (DDM) DRIVER DOOR SILL PLATE LAMP FRONT PASSENGER DOOR LATCH ASSEMBLY (FRONT PASSENGER'S DOOR.) FRONT PASSENGER DOOR MODULE (FPDM) GMLAN LOW SPEED GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES I/P COMPARTMENT LAMP INSTRUMENT ILLUMINATION CIRCUIT LEFT FRONT DOOR COURTESY LAMP LEFT REAR DOOR SILL PLATE LAMP LF DOOR AJAR SW SIG LF DOOR SW LOW REF LO SPD GMLAN SERIAL DATA LR DR AJAR SW SIG LT BLU WIRE LT BLU/BLK WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE PASSENGER DOOR SILL PLATE LAMP PNK WIRE PPL REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RED WIRE RF DOOR AJAR SW SIG RF DOOR SW LOW REF RIGHT FRONT DOOR COURTESY LAMP RIGHT REAR DOOR SILL PLATE LAMP RR DR AJAR SW SIG TAN WIRE TAN/PNK WIRE TAN/WHT WIRE YEL WIRE

ACC VOLT BATT POS VOLT BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE GMLAN SERIAL DATA HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT PANEL CLUSTER (IPC) LO SPD GMLAN SERIAL DATA LOGIC OFF ORG/ WIRE ORG/PNK WIRE PASSKEY FUSE 13 PNK PNK WIRE PNK WIRE POWER DISTRIBUTION SYSTEM REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RUN WIRE SECURITY IND SW-IGN FUSE 21 THEFT DETERRENT MODULE (TDM) (TOP RIGHT SIDE OF STEERING COLUMN) YEL WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 BATT POSITIVE VOLTAGE 5611 350 5608 5609 PPL SENSOR SIGNAL GND SENSOR SIGNAL VOLTAGE REFERENCE AIR BAG IND BLK WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DRIVER INFLATABLE RESTRAINT ROOF RAIL MODULE (IF EQUIPPED) (LEFT "C" PILLAR) DRIVER SEAT BELT PRETENSIONER (BASE OF LEFT "B" PILLAR) GRY WIRE GRY/DK GRN WIRE HOT AT ALL TIMES INFLATABLE RESTRAINT I/P MODULE INDICATOR INSTRUMENT PANEL CLUSTER (IPC) LO SPD GMLAN SERIAL DATA LOGIC LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE NCA WIRE OFF ORG/ WIRE ORG/BLK WIRE PASS AIR BAG OFF IND CTRL PASS AIR BAG ON IND CTRL PASS SEAT BELT IND PASSENGER AIR BAG IND PASSENGER INFLATABLE RESTRAINT SEAT BELT TENSION SENSOR PASSENGER SEAT BELT IND PASSENGER SEAT BELT PRETENSIONER (BASE OF RIGHT "C" PILLAR) PNK WIRE PNK/BLK WIRE PNK/RED WIRE PNK/TAN WIRE PPL PPL/WHT WIRE REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RED WIRE RED/LT BLU WIRE RIGHT INFLATABLE RESTRAINT ROOF RAIL MODULE (IF EQUIPPED) (RIGHT "C" PILLAR) SDM FUSE 30 SERIAL IGN DATA SHORTING BAR TAN WIRE TAN/BLK WIRE TAN/PPL WIRE WHT WIRE YEL WIRE YEL/BLK WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 BATT POSITIVE VOLTAGE 5611 350 5608 5609 PPL SENSOR SIGNAL GND SENSOR SIGNAL VOLTAGE REFERENCE AIR BAG IND BLK WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE GRY WIRE GRY/DK GRN WIRE HOT AT ALL TIMES INFLATABLE RESTRAINT I/P MODULE INDICATOR INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT SEAT BELT PRETENSIONER (BASE OF LEFT "B" PILLAR) LEFT INFLATABLE RESTRAINT ROOF RAIL MODULE (IF EQUIPPED) (LEFT "C" PILLAR) LO SPD GMLAN SERIAL DATA LOGIC LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE NCA WIRE OFF ORG/ WIRE ORG/BLK WIRE PASS AIR BAG OFF IND CTRL PASS AIR BAG ON IND CTRL PASS SEAT BELT IND PASSENGER AIR BAG IND PASSENGER INFLATABLE RESTRAINT SEAT BELT TENSION SENSOR PASSENGER SEAT BELT IND PNK WIRE PNK/BLK WIRE PNK/RED WIRE PNK/TAN WIRE PPL PPL/WHT WIRE REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RED WIRE RED/LT BLU WIRE RIGHT FRONT SEAT BELT PRETENSIONER (BASE OF RIGHT "C" PILLAR) RIGHT INFLATABLE RESTRAINT ROOF RAIL MODULE (IF EQUIPPED) (RIGHT "C" PILLAR) SDM FUSE 30 SERIAL IGN DATA SHORTING BAR TAN WIRE TAN/BLK WIRE TAN/PPL WIRE WHT WIRE YEL WIRE YEL/BLK WIRE
