Cadillac DTS I (2005-2011) courtesy lmp rly coil cntrl Wiring diagram
This page shows the only wiring diagram for the component.courtesy lmp rly coil cntrl, which is found in the car Cadillac DTS I (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram courtesy lmp rly coil cntrl (1 of 1)
BACKLIGHT LAMP CONTROL R TAIL LMP OUT DETECTION SIG PPL
BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
COURTESY LMP RLY COIL CNTRL
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DOOR LCK MTR LOCK CTRL
DOOR LCK MTR UNLOCK CTRL
DOOR LOCKS SYSTEM
GRY WIRE
GRY/BLK WIRE
INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM
INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
LED DIMMING SIGNAL
LOW SPEED GMLAN SERIAL DATA
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/GRY WIRE
PPL/WHT WIRE
REAR ACCESS OPEN SW SIGNAL
TRUNK AJAR SWITCH SIGNAL
TRUNK RELEASE RELAY CONTROL
TRUNK, TAILGATE, FUEL DOORS SYSTEM
YEL WIRE
Go to component -> Body control modules circuit (3 of 3) -> COURTESY LMP RLY COIL CNTRL
