Cadillac DTS I (2005-2011) a/t shift lever position ind Wiring diagram
This page shows the only wiring diagram for the component.a/t shift lever position ind, which is found in the car Cadillac DTS I (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/t shift lever position ind (1 of 1)
2 18 3 BATT POS VOLT COURTESY LP SW ON SIG INST PANEL LP SPLY
25 22 LED DIMMING SIG GMLAN LOW SPEED
A/T SHIFT LEVER POSITION IND
AUXILIARY HVAC CONTROL MODULE (IF EQUIPPED) (REAR OF CENTER CONSOLE) (LUXURY)
BCM (DIM) FUSE 18
BLK WIRE
BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
GARAGE DOOR OPENER (GDO)
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (TOP OF STEERING COLUMN)
INST PANEL LP SPLY BACKLIGHT LP CTRL
LEFT STEERING WHEEL CONTROL SWITCH
LIMOUSINE
ORG/WHT WIRE
PNK WIRE
PNK/BLK WIRE
PNK/DK BLU WIRE
PPL
PPL/WHT WIRE
PROVISION
REAR COMPARTMENT COURTESY LAMP (HEARSE, LIMOUSINE)
REAR FUSE BLOCK (UNDER LEFT REAR SEAT)
REAR WINDOW SUN SHADE
RED WIRE
RIGHT MIDDLE WINDOW SWITCH
RIGHT REAR HEATED SEAT SWITCH
RIGHT REAR SEAT LUMBAR SWITCH
RIGHT REAR WINDOW SWITCH
RIGHT STEERING WHEEL CONTROL SWITCH
STG ILLUM FUSE 8
SUNROOF CONTROL MODULE (UNDER FRONT (REAR PASSENGER'S SEAT) OF SUN ROOF)
SUNROOF SWITCH
SWITCH (IF EQUIPPED)
TAN WIRE
TAN/GRY WIRE
VALET MODE SW SIG
VALET SWITCH
W/ LUXURY FRONT BUCKET SEAT 1491 (OR 8)
W/ SUNROOF
W/O LUXURY FRONT BUCKET SEAT
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> A/T SHIFT LEVER POSITION IND
