Cadillac DTS I (2005-2011) 5611 350 5608 5609 ppl sensor signal gnd sensor signal voltage reference Wiring diagrams

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 BATT POSITIVE VOLTAGE 5611 350 5608 5609 PPL SENSOR SIGNAL GND SENSOR SIGNAL VOLTAGE REFERENCE AIR BAG IND BLK WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DRIVER INFLATABLE RESTRAINT ROOF RAIL MODULE (IF EQUIPPED) (LEFT "C" PILLAR) DRIVER SEAT BELT PRETENSIONER (BASE OF LEFT "B" PILLAR) GRY WIRE GRY/DK GRN WIRE HOT AT ALL TIMES INFLATABLE RESTRAINT I/P MODULE INDICATOR INSTRUMENT PANEL CLUSTER (IPC) LO SPD GMLAN SERIAL DATA LOGIC LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE NCA WIRE OFF ORG/ WIRE ORG/BLK WIRE PASS AIR BAG OFF IND CTRL PASS AIR BAG ON IND CTRL PASS SEAT BELT IND PASSENGER AIR BAG IND PASSENGER INFLATABLE RESTRAINT SEAT BELT TENSION SENSOR PASSENGER SEAT BELT IND PASSENGER SEAT BELT PRETENSIONER (BASE OF RIGHT "C" PILLAR) PNK WIRE PNK/BLK WIRE PNK/RED WIRE PNK/TAN WIRE PPL PPL/WHT WIRE REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RED WIRE RED/LT BLU WIRE RIGHT INFLATABLE RESTRAINT ROOF RAIL MODULE (IF EQUIPPED) (RIGHT "C" PILLAR) SDM FUSE 30 SERIAL IGN DATA SHORTING BAR TAN WIRE TAN/BLK WIRE TAN/PPL WIRE WHT WIRE YEL WIRE YEL/BLK WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 BATT POSITIVE VOLTAGE 5611 350 5608 5609 PPL SENSOR SIGNAL GND SENSOR SIGNAL VOLTAGE REFERENCE AIR BAG IND BLK WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE GRY WIRE GRY/DK GRN WIRE HOT AT ALL TIMES INFLATABLE RESTRAINT I/P MODULE INDICATOR INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT SEAT BELT PRETENSIONER (BASE OF LEFT "B" PILLAR) LEFT INFLATABLE RESTRAINT ROOF RAIL MODULE (IF EQUIPPED) (LEFT "C" PILLAR) LO SPD GMLAN SERIAL DATA LOGIC LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE NCA WIRE OFF ORG/ WIRE ORG/BLK WIRE PASS AIR BAG OFF IND CTRL PASS AIR BAG ON IND CTRL PASS SEAT BELT IND PASSENGER AIR BAG IND PASSENGER INFLATABLE RESTRAINT SEAT BELT TENSION SENSOR PASSENGER SEAT BELT IND PNK WIRE PNK/BLK WIRE PNK/RED WIRE PNK/TAN WIRE PPL PPL/WHT WIRE REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RED WIRE RED/LT BLU WIRE RIGHT FRONT SEAT BELT PRETENSIONER (BASE OF RIGHT "C" PILLAR) RIGHT INFLATABLE RESTRAINT ROOF RAIL MODULE (IF EQUIPPED) (RIGHT "C" PILLAR) SDM FUSE 30 SERIAL IGN DATA SHORTING BAR TAN WIRE TAN/BLK WIRE TAN/PPL WIRE WHT WIRE YEL WIRE YEL/BLK WIRE
