Cadillac DTS I (2005-2011) 5060 1178 746 computer data lines system Wiring diagram

14 15 RR DR AJAR SW SIG LR DR AJAR SW SIG 33 53 65 GMLAN SERIAL DATA- GMLAN SERIAL DATA+ OIL PRESS SW SIG 5060 1178 746 COMPUTER DATA LINES SYSTEM 9 44 LOW REF FUEL LEVEL 9 5 13 GMLAN SERIAL DATA LOW REF DOOR AJAR SW SIG AJAR BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH) BRAKE FLUID LEVEL SWITCH (IN MASTER CYLINDER RESERVOIR) BRN WIRE COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE DRIVER DOOR LATCH ASSEMBLY (REAR OF DRIVER'S DOOR) DRIVER DOOR MODULE (DDM) DRIVER INFORMATION DISPLAY SWITCH ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROLS SYSTEM ENGINE OIL PRESSURE (EOP) SWITCH (LEFT SIDE OF ENGINE, ON OIL FILTER ADAPTER) FRONT PASSENGER DOOR LATCH ASSEMBLY (FRONT PASSENGER'S DOOR.) FRONT PASSENGER DOOR MODULE (FPDM) FUEL PUMP/ SENDER ASSEMBLY (IN FUEL TANK) GMLAN SERIAL DATA GRN WIRE GRY WIRE GRY/BLK WIRE LEFT MIDDLE DOOR LATCH ASSEMBLY (LIMOUSINE) (LEFT MIDDLE DOOR TRIM PANEL) LEFT REAR DOOR LATCH ASSEMBLY (REAR OF LEFT REAR DOOR) LOGIC LOW REF DOOR AJAR SW SIG GMLAN SERIAL DATA LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN/BLK WIRE PARK BRAKE SW SIG PARK BRAKE SWITCH (ON PARK BRAKE PEDAL) PERSONA- LIZATION PNK WIRE PPL PPL/BLK WIRE RIGHT MIDDLE DOOR LATCH ASSEMBLY (LIMOUSINE) (RIGHT MIDDLE DOOR TRIM PANEL) RIGHT REAR DOOR LATCH ASSEMBLY (RIGHT REAR DOOR) SET/ RESET TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TRIP/ FUEL VEHICLE INFORMATION WHT WIRE YEL WIRE YEL/DK GRN WIRE
