Cadillac DTS I (2005-2011) 2 18 3 batt pos volt courtesy lp sw on sig inst panel lp sply Wiring diagram

2 18 3 BATT POS VOLT COURTESY LP SW ON SIG INST PANEL LP SPLY 25 22 LED DIMMING SIG GMLAN LOW SPEED A/T SHIFT LEVER POSITION IND AUXILIARY HVAC CONTROL MODULE (IF EQUIPPED) (REAR OF CENTER CONSOLE) (LUXURY) BCM (DIM) FUSE 18 BLK WIRE BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE GARAGE DOOR OPENER (GDO) GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (TOP OF STEERING COLUMN) INST PANEL LP SPLY BACKLIGHT LP CTRL LEFT STEERING WHEEL CONTROL SWITCH LIMOUSINE ORG/WHT WIRE PNK WIRE PNK/BLK WIRE PNK/DK BLU WIRE PPL PPL/WHT WIRE PROVISION REAR COMPARTMENT COURTESY LAMP (HEARSE, LIMOUSINE) REAR FUSE BLOCK (UNDER LEFT REAR SEAT) REAR WINDOW SUN SHADE RED WIRE RIGHT MIDDLE WINDOW SWITCH RIGHT REAR HEATED SEAT SWITCH RIGHT REAR SEAT LUMBAR SWITCH RIGHT REAR WINDOW SWITCH RIGHT STEERING WHEEL CONTROL SWITCH STG ILLUM FUSE 8 SUNROOF CONTROL MODULE (UNDER FRONT (REAR PASSENGER'S SEAT) OF SUN ROOF) SUNROOF SWITCH SWITCH (IF EQUIPPED) TAN WIRE TAN/GRY WIRE VALET MODE SW SIG VALET SWITCH W/ LUXURY FRONT BUCKET SEAT 1491 (OR 8) W/ SUNROOF W/O LUXURY FRONT BUCKET SEAT WHT WIRE YEL WIRE
