Cadillac CTS II (2007-2014) Awd circuit

AWD FUSE BATT GROUND BLK WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DRIVER INFORMATION LOGIC CENTER (DIC) ECM, TCM IGN FUSE GMLAN HOT AT ALL TIMES HOT W/ IGN 1 RELAY ENERGIZED INSTRUMENT PANEL CLUSTER (IPC) MODULE (BCM) PNK WIRE POWER DISTRIBUTION SYSTEM PPL PPL 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 OIL TEMP SENS SIG PPL/WHT WIRE RED/WHT WIRE RESISTOR SIG SERIAL DATA BUS (+) SERIAL DATA BUS (-) TAN WIRE TAN/BLK WIRE TRANSFER CASE CLUTCH COIL (REAR OF TRANSFER CASE) TRANSFER CASE FLUID TEMPERATURE SENSOR (REAR OF TRANSFER CASE) TRANSFER CASE SHIFT CONTROL MODULE (RIGHT SIDE OF DASH) UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) WAKEUP SERIAL DATA YEL/BLK WIRE YEL/WHT WIRE
