Car Wiring Diagrams for Ignition lock solenoid circuit for Cadillac CTS II (2007-2014)

A/T AUTOMATIC TRANSMISSION SHIFT LEVER B+ SHIFT BLK WIRE BLK/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) BCM 1 FUSE IGNITION LOCK CYLINDER CONTROL ACTUATOR (ON STEERING COLUMN) IGNITION LOCK CYLINDER CONTROL SWITCH M/T POSITION SIGNAL PPL PPL/WHT WIRE REAR FUSE BLOCK (RIGHT REAR OF LUGGAGE COMPT) RED WIRE RED/WHT WIRE RKE/ PASS KEY/ MDL FUSE SHIFT POSITION SIGNAL W/ REMOTE W/O REMOTE WHT WIRE
