Automatic day/night mirror circuit, with infotainment system 5.1/7/8 for Cadillac CTS II (2007-2014)

8 9 DATA BUS (+) DATA BUS (-) AUTOMATIC DAY/NIGHT MIRROR BACKUP LAMP SUPPLY VOLT BACKUP LP SPLY VOLT BATT POSITIVE VOLT KEYPAD SIG KEYPAD SPLY VOLT KEYPAD GREEN LED SIG BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BRANCH BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DATA BUS+ DATA BUS- GND DK GRN/WHT WIRE EMERGENCY IND EMERGENCY SWITCH GROUND HOT AT ALL TIMES HOT W/ IGN 1 RELAY ENERGIZED IGN INSIDE REARVIEW MIRROR (ISRVM) ISRVM FUSE KEYPAD KEYPAD GREEN LED IND KEYPAD RED LED SIG WIRE LOGIC LT GRN WIRE LT GRN/BLK WIRE ON STAR BUTTON ASSEMBLY ONSTAR FUSE ONSTAR IND ONSTAR SWITCH PHONE IND PHONE SWITCH PNK WIRE REAR FUSE BLOCK (RIGHT REAR OF LUGGAGE COMPT) RED LED IND WIRE RED/WHT WIRE TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (BEHIND RIGHT REAR STRUT TOWER) YEL/BLK WIRE
