Car Wiring Diagrams for Cooling fan circuit for Cadillac CTS II (2007-2014)

3.0L&3.6L 3.6L, 3.0L 6.2L BLK WIRE CHARGE AIR COOLER (CAC) COOLANT PUMP CHARGE AIR COOLER (CAC) COOLANT PUMP RELAY (6.2L) CHARGE AIR COOLER COOLANT PUMP CTRL COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE ECT SENS SIG EMIS 2 FUSE ENGINE COOLING FAN ENGINE COOLING FAN RESISTER FAN 1 FUSE (3.6L, 3.0L) (6.2L) FAN 1 RELAY FAN 2 RELAY FAN S/P RELAY FAN-2 FUSE GRY WIRE HI SPD COOLING FAN RLY CTRL HI SPD GMLAN SERIAL DATA BUS + HOT AT ALL TIMES HOT W/ PWR/ TRN RELAY ENERGIZED HVAC CONTROL MODULE (CENTER OF DASH) INCLR FUSE LEFT COOLING FAN (LEFT SIDE OF RADIATOR) LEFT FRONT STRUT TOWER) LO REF LO SPD COOLING FAN RLY CTRL LO SPD GMLAN SERIAL DATA LT BLU WIRE PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM RED/WHT WIRE RIGHT COOLING FAN (RIGHT SIDE OF RADIATOR) TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) WHT WIRE YEL WIRE
