Cadillac CTS II (2007-2014) w/o relaro front bucket seats dk Wiring diagram
This page shows the only wiring diagram for the component.w/o relaro front bucket seats dk, which is found in the car Cadillac CTS II (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o relaro front bucket seats dk (1 of 1)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
COUPE
DK BLU WIRE
DK GRN WIRE
DOWN SWITCH
DRV PWR SEAT CIRCUIT BREAKER
HIGH IND
HOT AT ALL TIMES
LEFT COOLING
LEFT FAN
LEFT FAN UP
LEFT HEATED
LOGIC
LOW IND
MED IND
MEMORY SYSTEMS
MSM (RIGHT REAR FUSE OF LUGGAGE COMPT)
NCA WIRE
PASSENGER SEAT CUSHION VENTILATION HEATING, COOLING MODULE
PNK WIRE
PNK/ DK WIRE
RADIO/HVAC CONTROL (CENTER OF DASH)
REAR FUSE BLOCK
RED WIRE
RED/WHT WIRE
RIGHT COOLING SWITCH
RIGHT FAN DOWN SWITCH
RIGHT FAN UP SWITCH
RIGHT HEATED SEAT HIGH SWITCH
SEAT HIGH SWITCH
SEDAN WAGON
SWITCH
W/ RECARO FRONT BUCKET SEAT
W/ RECARO FRONT BUCKET SEATS
W/O RECARO FRONT DK BUCKET SEATS PNK WIRE
W/O RELARO FRONT BUCKET SEATS DK
WHT WIRE
Go to component -> Heated seats circuit (2 of 2) -> W/O RELARO FRONT BUCKET SEATS DK
