Cadillac CTS II (2007-2014) remote radio ctrl sply volt Wiring diagram

15 14 13 5 VOLT REF LOW REF STP LMP SW SIG 5 VOLT REF A/T ABS IND. BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/YEL WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BRAKE BOOSTER VACUUM SENSOR (EXCEPT 6.2L) (ON BOOSTER) BRAKE IND BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL) BRAKE POSITION SENSOR SIGNAL BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY ENGINE CONTROL MODULE (ECM) (EXCEPT 6.2L: LEFT FRONT OF ENGINE COMPT) EXCEPT 6.2L 6.2L GRY WIRE HIGH SPD GMLAN SERIAL DATA HIGH SPEED GMLAN SERIAL DATA BUS + INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (TOP OF STEERING COLUMN) INSTRUMENT PANEL CLUSTER (IPC) LOGIC LOW REF LOW SPD GMLAN SERIAL DATA NCA WIRE ORG/ WIRE ORG/BLK WIRE PARK BRAKE SWITCH (ON PARK BRAKE ASSEMBLY) PARK BRK SW SIG PPL RED WIRE RED/WHT WIRE REMOTE RADIO CTRL SPLY VOLT RIGHT FRONT WHEEL SPEED SENSOR (WSS) (RIGHT FRONT WHEEL HUB ASSEMBLY) RIGHT STEERING WHEEL CONTROL SWITCH SEEK DOWN SEEK UP SOUND SYSTEMS STEERING WHEEL CTRLS SIG TAN WIRE TAN/BLK WIRE TRACTION CONTROL OFF IND TRACTION CONTROL SWITCH LEFT STEERING WHEEL CONTROL SWITCH (6.2L) TRACTION CONTROL SWITCH RADIO/HVAC CONTROL (EXCEPT 6.2L) TRACTION CTRL SW SIG TRANSMISSIONS, PPL CRUISE CONTROL SYSTEMS (STEERING WHEEL HARNESS) VARIABLE EFFORT STEERING ACTUATOR (POWER STEERING RACK ASSEMBLY) VOICE 1 5 PPL PPL VOL (-) VSC IND WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
