Cadillac CTS II (2007-2014) onstar switch Wiring diagrams

This page contains all the electrical diagrams for the component. onstar switch, in which he is found in the car Cadillac CTS II (2007-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram onstar switch (1 of 3)

Wiring diagram onstar switch for Cadillac CTS II (2007-2014) (1 of 3)

Get access

10 12 7 DATA BUS+ DATA BUS- GND 15 11 6 BATT POSITIVE VOLT KEYPAD SIG KEYPAD SPLY VOLT AUTOMATIC DAY/NIGHT MIRROR BACKUP LAMP SUPPLY VOLT BLK WIRE BLK/WHT WIRE COMPUTER DATA LINES SYSTEM DISPLAY DK GRN WIRE DK GRN/WHT WIRE EMERGENCY IND EMERGENCY SWITCH GARAGE DOOR OPENER (GDO) GROUND HOT AT ALL TIMES HOT AT ALL TIMES THEFT/ UGDO FUSE INSIDE REARVIEW MIRROR (ISRVM) KEYPAD KEYPAD GREEN LED IND KEYPAD GREEN LED IND SIG KEYPAD RED WIRE LED IND SIG B+ LOGIC LT BLU WIRE LT GRN/BLK WIRE LUGGAGE COMPT) NAVIGATION SYSTEM ON STAR BUTTON ASSEMBLY ONSTAR FUSE ONSTAR IND ONSTAR SWITCH PHONE IND PHONE SWITCH PNK WIRE REAR FUSE BLOCK (RIGHT REAR OF RED LED IND WIRE RED/WHT WIRE TAN WIRE TAN/BLK WIRE VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (BEHIND RIGHT REAR STRUT TOWER)

Go to component -> Automatic day/night mirror circuit, with infotainment system 1/2/3 & rearview camera -> ONSTAR SWITCH

Wiring diagram onstar switch (2 of 3)

Wiring diagram onstar switch for Cadillac CTS II (2007-2014) (2 of 3)

Get access

8 9 DATA BUS (+) DATA BUS (-) AUTOMATIC DAY/NIGHT MIRROR BACKUP LAMP SUPPLY VOLT BACKUP LP SPLY VOLT BATT POSITIVE VOLT KEYPAD SIG KEYPAD SPLY VOLT KEYPAD GREEN LED SIG BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BRANCH BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DATA BUS+ DATA BUS- GND DK GRN/WHT WIRE EMERGENCY IND EMERGENCY SWITCH GROUND HOT AT ALL TIMES HOT W/ IGN 1 RELAY ENERGIZED IGN INSIDE REARVIEW MIRROR (ISRVM) ISRVM FUSE KEYPAD KEYPAD GREEN LED IND KEYPAD RED LED SIG WIRE LOGIC LT GRN WIRE LT GRN/BLK WIRE ON STAR BUTTON ASSEMBLY ONSTAR FUSE ONSTAR IND ONSTAR SWITCH PHONE IND PHONE SWITCH PNK WIRE REAR FUSE BLOCK (RIGHT REAR OF LUGGAGE COMPT) RED LED IND WIRE RED/WHT WIRE TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (BEHIND RIGHT REAR STRUT TOWER) YEL/BLK WIRE

Go to component -> Automatic day/night mirror circuit, with infotainment system 1/2/3 without rearview camera -> ONSTAR SWITCH
