Cadillac CTS II (2007-2014) mtr lo ref wiring diagram
This page shows the only wiring diagram for the component.mtr lo ref, which is found in the car Cadillac CTS II (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
mtr lo ref wiring diagram (1 of 1)
AFS FUSE
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA BUS - DATA BUS -
DK GRN WIRE
GND MTR SIG 2 MTR SIG 4
GRY WIRE
HEADLAMP CONTROL MODULE (FRONT OF ENGINE COMPT)
HOT AT ALL TIMES
LEFT ADAPTIVE FORWARD LIGHTING (AFL) MOTOR
LEFT HEADLAMP
LT BLU WIRE
LT GRN/BLK WIRE
MTR LO REF
MTR SIG 1 MTR SIG 3
MTR SIG 3 FORWARD LIGHTING SYSTEM
NCA WIRE
ORG/ WIRE
PNK WIRE
RIGHT ADAPTIVE FORWARD LIGHTING (AFL) MOTOR
RIGHT HEADLAMP
SERIAL DATA MTR LO REF MTR SIG 2 MTR SIG 4
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT)
YEL WIRE
Go to component -> Adaptive front lighting circuit -> MTR LO REF
