Cadillac CTS II (2007-2014) lf sens vol ref rf sens vol ref lr sens vol ref rr sens vol ref Wiring diagram

BATTERY VOLTAGE LR POSITION SENS BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DISPLAY FUSE DK GRN WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY ELECTRONIC SUSPENSION CONTROL (ESC) MODULE (LEFT SIDE OF LUGGAGE COMPT) GMLAN SER DATA - GMLAN SER DATA + LF SENSOR LOW REF RR DAMPING CTRL GMLAN SER DATA - GMLAN SER DATA + RF SENSOR LOW REF LR SENSOR LOW REF GMLAN SERIAL DATA GRN WIRE HOT AT ALL TIMES LEFT FRONT SHOCK ABSORBER ACTUATOR (TOP OF LEFT FRONT SHOCK) LEFT FRONT SUSPENSION POSITION SENSOR (IN LEFT FRONT STRUT TOWER) LEFT REAR SHOCK ABSORBER ACTUATOR (TOP OF LEFT REAR SHOCK) LEFT REAR SUSPENSION POSITION SENSOR (IN LEFT REAR STRUT TOWER) LF POSITION SENS RF POSITION SENS RR POSITION SENS LF SENS VOL REF RF SENS VOL REF LR SENS VOL REF RR SENS VOL REF LO SPD GMALN SERIAL DATA LOGIC INSTRUMENT PANEL CLUSTER (IPC) LOGIC RADIO/HVAC CONTROL LR DAMPER LO REF RF DAMPER LO REF LF DAMPER LO REF SPD DATA COMM ENABLE LR DAMPING CTRL PPL RR DAMPER LO REF RF DAMPER CTRL LF DAMPER CTRL GROUND LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE MRRTD FUSE NCA WIRE ORG/ WIRE ORG/BLK WIRE POWER DISTRIBUTION SYSTEM PPL PPL/WHT WIRE RED WIRE RED/WHT WIRE RIDE CONTROL SWITCH RIGHT FRONT SHOCK ABSORBER ACTUATOR (TOP OF RIGHT FRONT SHOCK) RIGHT FRONT SUSPENSION POSITION SENSOR (IN RIGHT FRONT STRUT TOWER) RIGHT REAR SHOCK ABSORBER ACTUATOR (TOP OF RIGHT REAR SHOCK) RIGHT REAR SUSPENSION POSITION SENSOR (IN RIGHT REAR STRUT TOWER) RR SENSOR LOW REF TAN WIRE TAN/BLK WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE YEL WIRE
