Cadillac CTS II (2007-2014) head lamp wash relay Wiring diagrams
This page contains all the electrical diagrams for the component. head lamp wash relay, in which he is found in the car Cadillac CTS II (2007-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram head lamp wash relay (1 of 3)
15 7 WINDSHIELD RELAY CTRL WINDSHIELD WIPER MOTOR
3.0L, 3.6L 6.2L
7 20 21 HEADLAMP RELAY CTRL WINDSHIELD SW SIG 2 FR WIPER SW HIGH SIG
BLK WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH,
CENTER (DIC) DISPLAY
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK PPL
DRIVER INFORMATION
DRL WSW FUSE
GRN WIRE
GRY WIRE
HDM WASH FUSE
HEAD LAMP WASH RELAY
HEADLAMP WASHER FLUID PUMP (IF EQUIPPED) (IN WASHER RESERVOIR)
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW IND CTRL
LOW SPD GMLAN
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT)
WASHER SWITCH
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WIPER MOTOR (LEFT SIDE OF FIREWALL)
WINDSHIELD WIPER/WASHER SWITCH
WPR FUSE
WPR HI RELAY
WPR RELAY
WSW PUMP RELAY
YEL WIRE
Go to component -> Wiper/washer circuit, coupe -> HEAD LAMP WASH RELAY
Wiring diagram head lamp wash relay (2 of 3)
15 7 WINDSHIELD RELAY CTRL WINDSHIELD WIPER MOTOR
3.0L, 3.6L 6.2L
7 20 21 HEADLAMP RELAY CTRL WINDSHIELD SW SIG 2 FR WIPER SW HIGH SIG
BLK WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH,
CENTER (DIC) DISPLAY
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK PPL
DRIVER INFORMATION
DRL WSW FUSE
GRN WIRE
GRY WIRE
HDM WASH FUSE
HEAD LAMP WASH RELAY
HEADLAMP WASHER FLUID PUMP (IF EQUIPPED) (IN WASHER RESERVOIR)
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW IND CTRL
LOW SPD GMLAN
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT)
WASHER SWITCH
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WIPER MOTOR (LEFT SIDE OF FIREWALL)
WINDSHIELD WIPER/WASHER SWITCH
WPR FUSE
WPR HI RELAY
WPR RELAY
WSW PUMP RELAY
YEL WIRE
Go to component -> Wiper/washer circuit, sedan -> HEAD LAMP WASH RELAY
Wiring diagram head lamp wash relay (3 of 3)
BLK WIRE
BLU WIRE
DK BLU WIRE
DK DK
DK GRN WIRE
GRN WIRE
GRY WIRE
HDM WASH FUSE
HEAD LAMP WASH RELAY
HEADLAMP WASHER FLUID PUMP (IF EQUIPPED) (IN WASHER RESERVOIR)
HOT AT ALL TIMES
LOGIC
LT GRN WIRE
ORG/ WIRE
PPL
REAR FUSE BLOCK (RIGHT REAR OF LUGGAGE COMPT)
REAR WINDOW WASHER FLUID PUMP RELAY
REAR WINDOW WIPER MOTOR (CENTER OF LIFTGATE)
REAR WIPER FUSE
RED WIRE
RED/WHT WIRE
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT)
WASHER PUMP FUSE
WHT WIRE
WINDSHIELD WASHER FLUID PUMP (ON WASHER FLUID RESERVOIR)
WINDSHIELD WASHER PUMP RELAY
YEL WIRE
Go to component -> Wiper/washer circuit, wagon (2 of 2) -> HEAD LAMP WASH RELAY
