Cadillac CTS II (2007-2014) body control module wiring diagram
This page shows the only wiring diagram for the component.body control module, which is found in the car Cadillac CTS II (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
body control module wiring diagram (1 of 1)
BLK WIRE
BLK/RED WIRE
BODY CONTROL MODULE
BRN WIRE
CRUISE CTRL IND DIMMING SIG
DK GRN/WHT WIRE
HEATED STEERING WHEEL
HEATED STEERING WHEEL CONTROL MODULE
HEATED STEERING WHEEL ON IND
HEATED STEERING WHEEL SWITCH
HIGH CTRL
HOT W/ IGN 1 RELAY ENERGIZED
IGN
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (TOP OF STEERING COLUMN)
INLINE FUSE HEATED STEERING WHEEL CONTROL MODULE
LEFT STEERING WHEEL CONTROL SWITCH
MISC FUSE BLOCK IGN (RIGHT FRONT FUSE OF ENGINE COMPT)
NCA WIRE
ORG/ WIRE
PNK LED CTRL WIRE
PNK WIRE
RED WIRE
RED/GRY WIRE
SENS SIG
SW SIG
UNDERHOOD
VOLT REF
YEL WIRE
Go to component -> Heated steering wheel circuit -> BODY CONTROL MODULE
