Courtesy lamps circuit for Cadillac CTS I (2002-2007)

BLK WIRE CLASS 2 SERIAL DATA COMPUTER DATA LINES SYSTEM COURTESY LAMP SWITCH COURTESY LPS ON SIGNAL DIM/ ALDL FUSE DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DRIVER DOOR LATCH ASSEMBLY DRIVER DOOR MODULE (ON LEFT DOOR, UNDER DOOR TRIM) CLASS 2 SERIAL DATA DRIVER DOOR OPEN SW SIG FRONT PASSENGER DOOR LATCH ASSEMBLY FRONT PASSENGER DOOR SW SIG GROUND GRY WIRE HOT AT ALL TIMES I/P LAMPS DIMMER SWITCH INSTRUMENT ILLUMINATION CIRCUIT LEFT COURTESY/READING LAMP LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR DOOR MODULE (UNDER DOOR TRIM PANEL) LEFT REAR DOOR OPEN SW SIG LT BLU/BLK WIRE LT GRN WIRE OVERHEAD CONSOLE PNK/BLK WIRE PPL RED/WHT WIRE RIGHT COURTESY/READING LAMP RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR DOOR MODULE RIGHT REAR DOOR OPEN SW SIG TAN WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPARTMENT) WHT WIRE YEL WIRE

BLK WIRE COMPUTER DATA LINES SYSTEM COURTESY LP VOLTAGE LID AJAR SW SIGNAL DK BLU WIRE DK BLU/WHT WIRE DRIVER SUNSHADE DRIVER VANITY LAMPS GRY WIRE HOT AT ALL TIMES INTERIOR LAMP FUSE INT LAMP RELAY JOINT CONNECTOR LEFT FOOTWELL COURTESY LAMP LEFT FRONT DOOR COURTESY LAMP NCA WIRE ORG/BLK WIRE PASSENGER SUNSHADE PASSENGER VANITY LAMPS PPL PPL 1807 1807 REAR COMPARTMENT COURTESY LAMP REAR DOME LAMP REAR INTEGRATION MODULE (UNDER PACKAGE SHELF TRIM PANEL) REAR SEAT) RIGHT FOOTWELL COURTESY LAMP RIGHT FRONT DOOR COURTESY LAMP RIGHT REAR FUSE BLOCK (BELOW RIGHT TRUNK DIODE WHT WIRE
