Cadillac CTS I (2002-2007) right rear fuse block Wiring diagrams

BLK WIRE BLK/WHT WIRE CLASS 2 SERIAL DATA DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DOOR OPEN ENGINE CONTROL MODULE (ECM) (3.6L (VIN 7): FRONT OF RIGHT VALVE COVER) FRONT PASSENGER DOOR LATCH ASSEMBLY FRONT PASSENGER DOOR MODULE (ON RIGHT FRONT DOOR, UNDER DOOR TRIM PANEL) GROUND HVAC CONTROL MODULE (BEHIND CENTER OF DASH, BELOW RADIO) IGN INSTRUMENT PANEL CLUSTER (IPC) LOGIC LT GRN WIRE ORG/BLK WIRE POWERTRAIN CONTROL MODULE PPL PPL 5.7L 2.8L/3.6L PPL CLASS 2 SERIAL DATA PPL CLASS 2 SERIAL DATA DOOR OPEN SW SIG PPL PPL PPL PPL 1807 1807 CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA PPL PPL 58 59 1807 1807 CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA PPL PPL 8 11 CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA PPL PPL PPL 1 2 3 4 5 6 7 PPL PPL PPL 6 1 2 PPL PPL PPL PPL 25 24 23 26 RADIO REAR COMPARTMENT LID RELEASE ACTUATOR (CENTER OF REAR COMPARTMENT LID) RIGHT REAR FUSE BLOCK SECURITY INDICATOR TAN/WHT WIRE TRUNK AJAR SWITCH SIGNAL TRUNK RELEASE MOTOR SUPPLY VOLTAGE

BLK WIRE BLU WIRE BRN WIRE DK BLU WIRE DK GRN WIRE GROUND GRY/BLK WIRE HALL EFFECT SENSOR 1 HALL EFFECT SENSOR 2 HOT AT ALL TIMES LIMIT SWITCH LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK PPL WIRE PPL SUNROOF SWITCH-DATA 6 SUNROOF SWITCH-DATA 2 RAP RELAY RAP RELAY COIL CTRL RAP RELAY SWITCH SUPPLY VOLTAGE CLOSE OPEN REAR INTEGRATION MODULE (UNDER PACKAGE SHELF TRIM PANEL) RIGHT REAR FUSE BLOCK SOLID STATE (CLOSE) SOLID STATE (OPEN) SUN ROOF MOD FUSE SUNROOF CONTROL SWITCH SUNROOF LIMIT SWITCH LOW REFERENCE SUNROOF MODULE SUNROOF MOTOR (AT LEFT FRONT CORNER OF SUNROOF MODULE) SUNROOF MOTOR CLOSE CONTROL SUNROOF MOTOR OPEN CONTROL TAN WIRE TAN/WHT WIRE YEL WIRE YEL/BLK WIRE
