Cadillac CTS I (2002-2007) right heated washer nozzle left heated washer nozzle Wiring diagram
This page shows the only wiring diagram for the component.right heated washer nozzle left heated washer nozzle, which is found in the car Cadillac CTS I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right heated washer nozzle left heated washer nozzle (1 of 1)
10 11 9 8 PNK PNK PNK PNK WIRE
5.7L
6 PNK WIRE
ACCESSORY IGNITION 1 PNK WIRE
BRN WIRE
CRUISE CONTROL SWITCH
DASH INTEGRATION MODULE (DIM)
ENGINE CONTROL MODULE (ECM)
EXCEPT 5.7L
FROM UNDERHOOD FUSE BLOCK
IGN MOD/MAF FUSE
IGNITION LOCK CYLINDER CONTROL ACTUATOR
IGNITION SWITCH
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
LEFT HEADLAMP
LOCK OFF
MASS AIR FLOW (MAF SENSOR)
ORG/ WIRE
PIN 37) (DIAGRAM 2 OF 7)
PNK 5.7L WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
REAR INTEGRATION MODULE (RIM)
RED WIRE
RED/BLK WIRE
RIGHT HEADLAMP
RIGHT HEATED WASHER NOZZLE LEFT HEATED WASHER NOZZLE
RIGHT REAR FUSE BLOCK (BELOW RIGHT REAR SEAT)
RIGHT STEERING WHEEL CONTROLS
RIM/ IGN SW FUSE
RUN WIRE
SPARE FUSE SPARE FUSE
SPLICE
STRG CTLS FUSE
TO LEFT REAR FUSE BLOCK (IGN 3 RELAY) (DIAGRAM 6 OF 7)
TO RIGHT REAR FUSE BLOCK (IGN 1 RELAY) (DIAGRAM 7 OF 7)
TO UNDERHOOD FUSE BLOCK (ACCESSORY RELAY)
TO UNDERHOOD FUSE BLOCK (CMP CLU RELAY) (DIAGRAM 3 OF 7)
TURN SIGNAL SWITCH
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPARTMENT)
W/ AUTOMATIC HEADLAMPS CONTROL LEVELING SYSTEM
WASH NOZ FUSE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 7) -> RIGHT HEATED WASHER NOZZLE LEFT HEATED WASHER NOZZLE
