Cadillac CTS I (2002-2007) recline motor forward control recline motor rearward control Wiring diagram
This page shows the only wiring diagram for the component.recline motor forward control recline motor rearward control, which is found in the car Cadillac CTS I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram recline motor forward control recline motor rearward control (1 of 1)
BATTERY POSITIVE VOLTAGE
BLK WIRE
BRN/WHT WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT ADJUSTER SWITCH
FRONT VERTICAL DOWN
FRONT VERTICAL MOTOR UP CONTROL LUMBER MOTOR FORWARD CONTROL
FRONT VERTICAL UP
GROUND BATTERY POSITIVE VOLTAGE
GRY WIRE
HORIZONTAL FORWARD
HORIZONTAL REARWARD
HOT AT ALL TIMES
LEFT REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
LT BLU WIRE
LT GRN WIRE
MEM/ADAPT SEAT FUSE
MEMORY SEAT MODULE (MSM) (UNDER DRIVER'S SEAT)
ORG/ WIRE
PNK WIRE
PPL
PPL CLASS 2 SERIAL DATA
REAR VERTICAL DOWN
REAR VERTICAL UP
RECLINE FORWARD
RECLINE MOTOR FORWARD CONTROL RECLINE MOTOR REARWARD CONTROL
RECLINE REARWARD
RED WIRE
SEAT CIRCUIT BREAKER
TAN WIRE
W/ HEATED SEATS
W/ PASSENGER POWER SEATS
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Memory seat circuit (1 of 2) -> RECLINE MOTOR FORWARD CONTROL RECLINE MOTOR REARWARD CONTROL
