Cadillac CTS I (2002-2007) rear integration module ignition switch Wiring diagram

A/T SHIFT LOCK CONTROL SOLENOID ASSEMBLY A/T SHIFT SHIFT LOCK CONTROL SOLENOID BLK WIRE BRN WIRE CCP FUSE DK BLU WIRE DR MOD PWR CIRCUIT BREAKER DRIVER DOOR MODULE (DDM) DRIVER HEATED SEAT MODULE DRIVER SEAT ADJUSTER SWITCH EARLY PRODUCTION EXCEPT 5.7L 5.7L FROM IGNITION SWITCH (PIN 5) (DIAGRAM 4 OF 7) FROM LEFT REAR FUSE BLOCK (TRK DR RELEASE FROM UNDERHOOD FUSE BLOCK FRONT HEADLAMP LEVELING SENSOR FUEL PUMP MOTOR RELAY FUEL PUMP MTR FUSE HDLP LEVELING FUSE HVAC CONTROL MODULE FRONT PASSENGER HEATED SEAT MODULE IGN 3 FUSE IGN-3 RELAY IGNITION LOCK CYLINDER CONTROL ACTUATOR JOINT CONNECTOR LEFT REAR DOOR MODULE (LRDM) FRONT PASSENGER DOOR MODULE (FPDM) LEFT REAR FUSE BLOCK (BELOW LEFT REAR SEAT) MEMORY SEAT MODULE (MSM) ORG/ WIRE PASSENGER SEAT ADJUSTER SWITCH PASSENGER LUMBAR ADJUSTER SWITCH R FRT HTD SEAT MOD FUSE CANISTER VENT FUSE RAP RELAY REAR DEFOG RELAY REAR HEADLAMP LEVELING SENSOR REAR INTEGRATION MODULE (RIM) REAR INTEGRATION MODULE IGNITION SWITCH RECIRCULATION ACTUATOR RED WIRE RIGHT REAR DOOR MODULE (RRDM) RIGHT REAR FUSE BLOCK (BELOW RIGHT REAR SEAT) RIM/IGN SW FUSE SEAT CIRCUIT BREAKER SPARE FUSE SPARE FUSE SPARE FUSE SUNROOF MOD FUSE SUNROOF MODULE TAN WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) W/ MEMORY W/ PASSENGER POWER SEATS W/ POWER LUMBAR CONTROL SEATS W/O MEMORY W/O PASSENGER POWER SEATS W/O POWER LUMBAR CONTROL SEATS WHT WIRE
