Cadillac CTS I (2002-2007) passenger presence system/static suppression module wiring diagram
This page shows the only wiring diagram for the component.passenger presence system/static suppression module, which is found in the car Cadillac CTS I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
passenger presence system/static suppression module wiring diagram (1 of 1)
7 8 9 10 11 12 13 PPL
AUTO OCCUPANT SENS
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CASE GROUND
DK BLU WIRE
DK GRN WIRE
DK PPL
DRIVER INFLATABLE RESTRAINT ROOF RAIL MODULE (ABOVE LEFT "C" PILLAR)
DRIVER INFLATABLE RESTRAINT SIDE IMPACT MODULE (ON LEFT SIDE OF LEFT FRONT SEAT)
DRIVER INFLATABLE RESTRAINT SIDE IMPACT SENSING MODULE
DRIVER SEAT BELT PRETENSIONER (RIGHT SIDE OF DRIVER'S SEAT)
GRN WIRE
GRY WIRE
HOT IN RUN OR CRANK
IGN
IGN 1
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER CENTER CONSOLE)
INFLATABLE RESTRAINT STEERING WHEEL MODULE (ON STEERING WHEEL)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (BELOW INFLATABLE
INSIDE REARVIEW MIRROR
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER INFLATABLE RESTRAINT SIDE IMPACT SENSING MODULE
PASSENGER PRESENCE SYSTEM/STATIC SUPPRESSION MODULE
PNK WIRE
PPL
PPL PPL COMPUTER DATA LINES SYSTEM
PPL/WHT WIRE
PSIR OFF
PSIR OFF IND
PSIR ON
PSIR ON IND
RESTRAINT STEERING WHEEL MODULE)
RIGHT REAR FUSE BLOCK (BELOW RIGHT REAR SEAT) AIRBAG FUSE
SENSOR SIGNAL
SHORTING BAR
SHORTING BAR SHORTING BAR
STAGE 1
STAGE 2
TAN WIRE
TAN/ORG WIRE
TAN/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> PASSENGER PRESENCE SYSTEM/STATIC SUPPRESSION MODULE
