Cadillac CTS I (2002-2007) message request logic Wiring diagram

5.7L 62 13 EXTENDED TRAVEL BRAKE SW SIG REQUESTED TORQUE SIGNAL 8 11 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA ABS FUSE ABS INDICATOR SIG BAS RELAY COIL SUPPLY VOLTAGE BAS RLY COIL SUPPLY VOLTAGE BLK WIRE BPP SENSOR SIGNAL BRAKE PEDAL POSITION SENSOR (NEAR TOP OF BRAKE PEDAL) BRAKE PUMP MOTOR BRN WIRE COMPUTER DATA LINES SYSTEM DELIVERED TORQUE SIGNAL DK BLU WIRE DK GRN WIRE ENGINE CONTROL MODULE (ECM) (FRONT OF RIGHT VALVE COVER) EXCEPT 5.7L GROUND HIGH EFFORT CTRL LOW EFFORT CTRL GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN OR START IGN 1 RELAY LOGIC LOW REFERENCE 5 VOLT REFERENCE LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MESSAGE CENTER MESSAGE REQUEST LOGIC NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK ABS FUSE WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) PPL RADIO RED/BLK WIRE REQUESTED TORQUE SIGNAL RIGHT REAR FUSE BLOCK (BELOW RIGHT REAR SEAT) SPLICE PACK TAN WIRE TAN/BLK WIRE THROTTLE ACTUATOR CONTROL (TAC) MODULE (RIGHT FRONT OF ENGINE COMPARTMENT) TRACTION CONTROL DATA SIG TRACTION CONTROL DATA SIGNAL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA PPL PPL TRACTION SUSPENDED SERVICE SUSPENSION SYS TRANSMISSIONS SYSTEM UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) VARIABLE EFFORT STEERING ACTUATOR (ON POWER STEERING GEAR INPUT SHAFT) W/ SOFT RIDE SUSPENSION SYSTEM WHT WIRE YEL WIRE YEL/BLK WIRE
