Cadillac CTS I (2002-2007) left heated washer nozzle Wiring diagram
This page shows the only wiring diagram for the component.left heated washer nozzle, which is found in the car Cadillac CTS I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left heated washer nozzle (1 of 1)
BATTERY
BLK WIRE
BLK/WHT WIRE
BLUNT CUT)
BRAKE FLUID LEVEL SWITCH
CELLULAR ANTENNA
COOLANT LEVEL SWITCH
DASH INTEGRATION MODULE (DIM)
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
HEADLAMP WASHER FLUID PUMP
IF EQUIPPED W/ HIGH PRESSURE HEADLAMP WASHER
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
LEFT HEATED WASHER NOZZLE
NCA WIRE
ORG/ WIRE
PASSENGER PRESENCE SYSTEM
REAR WINDOW DEFOGGER
RIGHT HEATED WASHER NOZZLE
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
W/O HIGH PRESSURE HEADLAMP WASHER
WASHER FLUID LEVEL SWITCH
WHT WIRE
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER/ WASHER MODULE
Go to component -> Ground distribution circuit (1 of 5) -> LEFT HEATED WASHER NOZZLE
