Cadillac CTS I (2002-2007) computer data lines system ppl class 2 serial data Wiring diagram
This page shows the only wiring diagram for the component.computer data lines system ppl class 2 serial data, which is found in the car Cadillac CTS I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram computer data lines system ppl class 2 serial data (1 of 1)
193 1807 COMPUTER DATA LINES SYSTEM PPL
4 8 628 607 LOW REFERENCE SUPPLY VOLTAGE
627 606 4 8 LOW REFERENCE SUPPLY VOLTAGE
BLK WIRE
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM PPL CLASS 2 SERIAL DATA
DRIVER DOOR MODULE (ON LEFT DOOR, UNDER DOOR TRIM)
DRIVER OUTSIDE REARVIEW MIRROR
FEED HEATED MIRROR ELEMENT
FRONT PASSENGER DOOR MODULE (ON RIGHT FRONT DOOR, UNDER DOOR TRIM PANEL)
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HVAC CONTROL MODULE (BEHIND CENTER OF DASH, BELOW RADIO)
NCA WIRE
ORG/ WIRE
PASSENGER OUTSIDE REARVIEW MIRROR FEED
PPL
REAR DEFOG FUSE
REAR DEFOG RELAY
REAR DEFOGGER INDICATOR
REAR DEFOGGER SWITCH LOGIC
REAR INTEGRATION MODULE (UNDER PACKAGE SHELF TRIM PANEL)
REAR WINDOW DEFOGGER GRID (ON REAR WINDOW GLASS)
RELAY CONTROL CLASS 2 SERIAL DATA
RIGHT REAR FUSE BLOCK (BELOW RIGHT REAR SEAT)
RTN
RTN HEATED MIRROR ELEMENT
WHT WIRE
Go to component -> Defoggers circuit -> COMPUTER DATA LINES SYSTEM PPL CLASS 2 SERIAL DATA
