Cadillac CTS I (2002-2007) camshaft actuator solenoid intake bank 1 Wiring diagram
This page shows the only wiring diagram for the component.camshaft actuator solenoid intake bank 1, which is found in the car Cadillac CTS I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram camshaft actuator solenoid intake bank 1 (1 of 1)
47 PNK WIRE
5.7L
AUXILIARY POWER OUTLET
BANK 1 SENSOR 1
BANK 2 SENSOR 1
BANK 2 SENSOR 1 (5.7L)
BLK WIRE
CAM FUSE
CAMSHAFT ACTUATOR SOLENOID EXHAUST BANK 2
CAMSHAFT ACTUATOR SOLENOID INTAKE BANK 1
CIGAR LIGHTER
CLUTCH PEDAL POSITION (CPP) SENSOR
CMP CLU RELAY
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE SOLENOID VALVE
EVEN INJ/ COIL FUSE
EXCEPT 5.7L
EXCEPT 5.7L 5.7L
FOG LAMP RELAY
FROM IGNITION SWITCH (VIA SPLICE
FROM UNDERHOOD FUSE BLOCK
FROM UNDERHOOD FUSE BLOCK (ACCESSORY RELAY) (DIAGRAM 2 OF 7)
FUEL INJECTOR 2
FUEL INJECTOR 4
FUEL INJECTOR 6
FUEL INJECTOR 6 FUEL INJECTOR 8
HEATED OXYGEN SENSOR
HTR VLV/ CLTCH FUSE
I/P OUTLET FUSE
IGN 1 RELAY
IGNITION COIL 2 IGNITION COIL 4
IGNITION COIL 6
IGNITION COIL/ MODULE 2
IGNITION COIL/ MODULE 6 IGNITION COIL/ MODULE 4
IGNITION COIL/ MODULE 8 FUEL INJECTOR 2
INSTRUMENT PANEL CLUSTER (IPC)
INTAKE MANIFOLD RUNNER CONTROL (IMRC) SOLENOID
OUTLET FUSE
PNK A/T WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
POWERTRAIN CONTROL MODULE (PCM)/ ENGINE CONTROL MODULE (ECM)
PPL
PPL PNK WIRE
PPL/WHT WIRE
RED WIRE
SPLICE PACK
STARTER FUSE
STARTER RELAY
TCM/IPC FUSE
THROTTLE ACTUATOR CONTROL (TAC) MODULE
TO UNDERHOOD FUSE BLOCK (WASH NOZ
TRANSMISSION CONTROL MODULE (TCM)
WHT WIRE
Go to component -> Power distribution circuit (3 of 7) -> CAMSHAFT ACTUATOR SOLENOID INTAKE BANK 1
