Cadillac CTS I (2002-2007) battery park lamp relay ctrl Wiring diagram
This page shows the only wiring diagram for the component.battery park lamp relay ctrl, which is found in the car Cadillac CTS I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery park lamp relay ctrl (1 of 1)
103 301 1538 1783 192 HEADLIGHTS SYSTEM WIPER/WASHER SYSTEM
1807 1807 COMPUTER DATA LINES SYSTEM
1970 1080 5052 1969 1483 5026 HEADLIGHTS SYSTEM
99 1717 EXTERIOR LIGHTS SYSTEM
BACKLIGHT LAMPS CONTROL
BATTERY
BATTERY PARK LAMP RELAY CTRL
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DIM/ ALDL FUSE
DIMMING FUSE
DK GRN WIRE
DK GRN/WHT WIRE
GRN WIRE
GROUND
GROUND DISTRIBUTION SYSTEM
HEADLIGHTS SYSTEM
HORNS SYSTEM
HOT AT ALL TIMES
IGNITION SWITCH
INST PANEL LP DIMMER SWITCH
LOCK OFF
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
PARK LAMP RELAY
PNK WIRE
PNK/BLK WIRE
PNK/WHT WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
RED WIRE
RED/WHT WIRE
RUN WIRE
SHIFT INTERLOCK SYSTEM
TAN WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT)
VOLTAGE CHECK FUSE
WARNING SYSTEM
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Dash integration module circuit -> BATTERY PARK LAMP RELAY CTRL
