Cadillac CTS I (2002-2007) bas relay Wiring diagrams
This page contains all the electrical diagrams for the component. bas relay, in which he is found in the car Cadillac CTS I (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
bas relay wiring diagram (1 of 3)
BAS FUSE
BAS RELAY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CLASS 2 (DIM) LIGHTS ON IND
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK DK
EARLY PRODUCTION LATE PRODUCTION
FROM UNDERHOOD FUSE BLOCK (DIMMING
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
JOINT CONNECTOR
LEFT FRONT MARKER LAMP
LEFT REAR MARKER LAMP LEFT TAIL/ STOP LAMP
LEFT REAR TURN SIGNAL LAMP LEFT TAIL LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TURN INDICATOR
LEFT TURN SIG IND LAMP SUPPLY VOLTAGE
LOGIC
LT BLU WIRE
LT BLU/WHT WIRE
LT PARK FUSE (DIAGRAM 1 OF 2)
MESSAGE CENTER TURN SIGNAL ON THEFT ATTEMPTED
MESSAGE REQUEST
NEAR RIGHT HEADLAMP) (ON RIGHT BODY RAIL, NEAR RIGHT HEADLAMP)
ORG/ WIRE
PPL
PPL (IN FORWARD LAMP HARNESS, 40 CM FROM HORN ASSEMBLY)
PPL EARLY PRODUCTION
PPL LATE PPL PRODUCTION W/ HID
PPL LT
RADIO
RED WIRE
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK LAMP
RIGHT HEADLAMP (W/O AUTOMATIC HEADLAMPS CONTROL LEVELING SYSTEM)
RIGHT REAR MARKER LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT TAIL LAMP
RIGHT TAIL LAMP ASSEMBLY
RIGHT TAIL/ STOP LAMP
RIGHT TURN INDICATOR GROUND
RIGHT TURN SIG IND LAMP SUPPLY VOLTAGE
RT PARK FUSE
TRAILERING (NOT USED)
W/ HID
W/O HID
WHT WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> BAS RELAY
bas relay wiring diagram (2 of 3)
AUDIO AMPLIFIER
BAS RELAY
BLK WIRE
BLUNT CUT)
CENTER HIGH MOUNTED STOP LAMP (CHMSL) LEFT BACKUP LAMP RIGHT BACKUP LAMP
COIL
FUEL PUMP MOTOR RELAY
FUEL PUMP, SENDER ASSEMBLY
IGN 1 RELAY
IGN-3 RELAY
INSIDE REARVIEW MIRROR (ISRVM)
LEFT REAR FOG LAMP
LEFT REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
LEFT REAR TAIL LAMP
LEFT REAR TAIL/ STOP LAMP LEFT REAR TURN SIGNAL LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT VANITY LAMPS COURTESY LAMPS
LICENSE LAMP ASSEMBLY
NCA WIRE
OVERHEAD CONSOLE DRIVER SUNSHADE
PASSENGER SUNSHADE
RADIO
REAR COMPARTMENT LID RELEASE ACTUATOR
REAR HEADLAMP LEVELING SENSOR
REAR INTEGRATION MODULE (RIM)
REAR WINDOW DEFOGGER
RIGHT LEFT LICENSE LAMP REAR FOG LAMP
RIGHT LICENSE LAMP LEFT REAR MARKER LAMP
RIGHT REAR MARKER LAMP
RIGHT REAR TAIL LAMP RIGHT REAR TAIL/STOP LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT TAIL LAMP ASSEMBLY
RIGHT VANITY LAMPS
SUNROOF CONTROL SWITCH
SUNROOF MODULE
W/ ELECTRIC SLIDING SUN ROOF GLASS
W/O ELECTRIC SLIDING SUN ROOF GLASS
WHT WIRE
Go to component -> Ground distribution circuit (4 of 5) -> BAS RELAY
bas relay wiring diagram (3 of 3)
AMP FUSE
AUDIO AMPLIFIER
AUDIO FUSE
BAS FUSE
BAS RELAY
BLK WIRE
BRN WIRE
DIGITAL RADIO RECEIVER
DRIVER ADJUSTER SEAT SWITCH
DRIVER DOOR MODULE (DDM)
DRIVER DR MOD FUSE
DRIVER HEATED SEAT MODULE
DRIVER LUMBAR ADJUSTER SWITCH
FROM UNDERHOOD FUSE BLOCK
GARAGE DOOR OPENER
JOINT CONNECTOR
L FRT HTD SEAT MOD FUSE
LEFT REAR DOOR MODULE (LRDM)
LEFT REAR FUSE BLOCK (IGN 3 RELAY) (DIAGRAM 6 OF 7)
MEM/ADAPT SEAT FUSE
MEMORY SEAT MODULE (MSM)
ORG/ WIRE
PUSHER FAN FUSE
PUSHER FAN RELAY (TRAILER PROVISIONS)
RADIO
RADIO ANTENNA MODULE
REAR DR MOD FUSE
RED WIRE
REV LAMP RELAY
REVERSE LAMP FUSE
RIGHT REAR DOOR MODULE (RRDM)
SPARE FUSE
TRK DR REL SOL RELAY
TRUNK DR RELEASE FUSE
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
W/ 7 SPEAKER SYSTEM
W/O 7 SPEAKER SYSTEM
WHT WIRE
Go to component -> Power distribution circuit (5 of 7) -> BAS RELAY
