Cadillac CTS I (2002-2007) backlight lamps control gnd Wiring diagram
This page shows the only wiring diagram for the component.backlight lamps control gnd, which is found in the car Cadillac CTS I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backlight lamps control gnd (1 of 1)
BACKLIGHT LAMPS CONTROL GND
BATTERY GROUND
BATTERY GROUND RTN GROUND BATTERY GROUND
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (ON LEFT DOOR, UNDER DOOR TRIM)
DRIVER DR MOD FUSE
DRIVER OUTSIDE REARVIEW MIRROR
EXIT (EXT)
FEED
GROUND
HORIZ MOTOR
HORIZ POS SENSOR
HOT AT ALL TIMES
LEFT HORIZ
LEFT LOGIC
LEFT REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
MEMORY 1 SWITCH SIGNAL
MEMORY 2 SWITCH SIGNAL
MEMORY/PERSONALIZATION FUNCTION SWITCH
NCA WIRE
OUTSIDE REARVIEW MIRROR SWITCH DRIVER DOOR SWITCH ASSEMBLY (DDSA)
PPL
PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
RED WIRE
RED/WHT WIRE
RIGHT
RIGHT HORIZ RTN
SEL LEFT
SEL RIGHT
VERT DOWN
VERT MOTOR
VERT POS SENSOR
VERT UP
VERTICAL POSIT SENSOR HORIZ POSIT SENSOR LOW REFERENCE
WHT WIRE
YEL WIRE
Go to component -> Memory mirrors circuit (1 of 2) -> BACKLIGHT LAMPS CONTROL GND
