Cadillac CTS I (2002-2007) 39 79 35 53 starte rly coil ctrl skip shift sol ctrl ccp switch ccp switch wiring diagram

12 13 UART SER DATA UART SER DATA 15 14 UART SER DATA UART SER DATA 39 79 35 53 STARTE RLY COIL CTRL SKIP SHIFT SOL CTRL CCP SWITCH CCP SWITCH BLK WIRE BRN/WHT WIRE CLUTCH PEDAL POSITION SWITCH (ON CLUTCH PEDAL BRACKET) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ECM FUSE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START HTR/VLV CLUTCH FUSE IGN 1 RELAY INSTRUMENT PANEL CLUSTER LOGIC LOW REF PNK WIRE LT GRN WIRE LT GRN/BLK WIRE MAIN RELAY ORG/BLK WIRE PNK PNK PNK 30 29 28 WIRE PNK WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE (PCM) PPL PPL LOW REF PPL/WHT WIRE REVERSE LOCKOUT SOLENOID (LEFT REAR OF TRANSMISSION) SKIP SHIFT IND SKIP SHIFT SOLENOID (LEFT SIDE OF TRANSMISSION) SPLICE PACK STARTER FUSE STARTER RELAY STARTING/ CHARGING SYSTEM TAN WIRE THROTTLE ACTUATOR CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) THROTTLE POSITION SENSOR TRANSMISSION FLUID TEMPERATURE SENSOR (IN TRANSMISSION) UNDER HOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (ON LEFT REAR OF TRANSMISSION) WHT WIRE YEL WIRE YEL/BLK WIRE
