Cadillac CTS I (2002-2007) 2540 41 battery ignition 3 voltage heated seat module status signal Wiring diagram

2540 41 BATTERY IGNITION 3 VOLTAGE HEATED SEAT MODULE STATUS SIGNAL 8 11 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA 9530 9534 HEATED SEAT ELEMENT CONTROL HEATED SEAT SENSOR LOW REF 9530 9534 HEATED SEAT ELEMENT CONTROL SEAT TEMP SENSOR LOW REF BATTERY IGNITION 3 VOLTAGE HEATED SEAT MODULE STATUS SIG BLK WIRE BLK/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DRIVER HEATED SEAT DRIVER HEATED SEAT STATUS PASSENGER HEATED SEAT STATUS DRIVER HEATED SEAT SWITCH DRIVER SEAT BACK HEATED SEAT ELEMENT DRIVER SEAT FRONT CUSHION HEATED SEAT ELEMENT DRIVER SEAT REAR CUSHION HEATED SEAT ELEMENT DRIVER'S HEATED SEAT MODULE (UNDER DRIVER'S SEAT) FRONT PASSENGER HEATED SEAT FRONT PASSENGER SEAT BACK HEATED SEAT ELEMENT FRONT PASSENGER SEAT CUSHION FRONT HEATED SEAT ELEMENT FRONT PASSENGER SEAT CUSHION REAR HEATED SEAT ELEMENT GROUND HEATED SEAT ELEMENT VOLTAGE HEATED SEAT TEMP SENS SIGNAL HOT AT ALL TIMES HOT W/ IGN 3 RELAY ENERGIZED IGN 3 FUSE JOINT CONNECTOR LEFT REAR FUSE BLOCK (BELOW LEFT REAR SEAT) LOGIC HVAC CONTROL MODULE (BEHIND CENTER OF DASH, BELOW RADIO) LT BLU/WHT WIRE LT FRT HTD SEAT MOD FUSE ORG/ WIRE PASSENGER HEATED SEAT SWITCH PASSENGER'S HEATED SEAT MODULE (UNDER PASSENGER'S SEAT) PNK HEATED SEAT HIGH/LOW SIGNAL WIRE PNK/BLK WIRE PPL PPL 1807 1807 CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA R FRT HTD SEAT MOD FUSE RADIO REAR INTEGRATION MODULE (UNDER PACKAGE SHELF TRIM PANEL) RED WIRE RIGHT REAR FUSE BLOCK (BELOW RIGHT REAR SEAT) SEAT TEMP SENSOR SIGNAL THERMISTOR WHT WIRE YEL WIRE
