Front heated seats circuit for Cadillac CT5 I (2019-2024)

BATT POS VOLT 52 BATT POS VOLT 66 BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BODY CTRL MODULE LIN BUS 11 BRN/BLK WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER FRONT SEAT BACK HEATER DRIVER FRONT SEAT CUSHION HEATER DRV HEATED BACK THERMISTOR LO REF DRV HEATED SEAT ELEMENT CTRL DRV HEATED SEAT ELEMENT LO REF DRV HEATED SEAT THERMISTOR LO REF DRV SEAT BACK HEATED TEMPERATURE SENS SIG DRV SEAT BLOWER MTR CTRL 1 DRV SEAT HEATED TEMPERATURE SENS SIG FRONT SEAT HEATER VENT CONTROL MODULE GND 22 GRN/BLK WIRE GRN/VIO WIRE GRY/BLK WIRE HAZARD WARNING SWITCH HOT AT ALL TIMES LOGIC LOW HEAT IND NCA WIRE PASS HEATED SEAT THERMISTOR LO REF PASS SEAT BACK HEATED TEMPERATURE SENS SIG PASS SEAT BLOWER MTR CTRL 1 PASS SEAT HEATED TEMPERATURE SENS SIG PASS SEAT HEATING ELEMENT CTRL PASS SEAT HEATING ELEMENT LO REF REAR BODY WIRING HARNESS JUNCTION BLOCK RED/BLU WIRE RED/BRN WIRE VIO/WHT WIRE WHT/BLU WIRE WHT/GRY WIRE YEL/GRY WIRE

BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BRN/BLU WIRE DRIVER FRONT SEAT BACK VENTILATION BLOWER DRIVER FRONT SEAT CUSHION VENTILATION BLOWER GRN/VIO WIRE GRY/BLK WIRE HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LOGIC NCA WIRE PASSENGER FRONT SEAT BACK HEATER PASSENGER FRONT SEAT BACK VENTILATION BLOWER PASSENGER FRONT SEAT CUSHION HEATER PASSENGER FRONT SEAT CUSHION VENTILATION BLOWER VIO/GRY WIRE VIO/WHT WIRE WHT/BLU WIRE WHT/GRY WIRE
