Headlights circuit for Cadillac CT5 I (2019-2024)

AUTOSAR CAN BATT POS VOLT BEAM CTRL BLK WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/YEL WIRE BRAKE MASTER CYLINDER) BRAKE SYSTEM CONTROL MODULE BUS (-) 2 SER CAN-BUS COMPUTER DATA LINES SYSTEM ENGINE WIRING HARNESS JUNCTION BLOCK GRN WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT DAYTIME RUNNING LAMP (W/O FRONT CORNERING LAMP) LEFT DAYTIME RUNNING LAMP, LEFT FRONT HEADLAMP LEFT HEADLAMP CONTROL MODULE LEFT HIGH BEAM HEADLAMP LEFT LOW BEAM HEADLAMP LF DRL CTRL LF LP ASSY 2 LF LP ASSY CTRL LH HDLP HI LH HDLP LO LH PRK LP CTRL 2 LIGHTING CONTROL MODULE LIN BUS 1 LOGIC RED/WHT WIRE RF DRL CTRL RH HDLP HI RH HDLP LO RH LP ASSY 2 RH PRK LP CTRL 2 RIGHT DAYTIME RUNNING LAMP RIGHT DAYTIME RUNNING LAMP (W/O FRONT CORNERING LAMP) RIGHT FRONT HEADLAMP RIGHT HEADLAMP CONTROL MODULE RIGHT HIGH BEAM HEADLAMP RIGHT LOW BEAM HEADLAMP SECONDARY FUSED SPLY VOLT WHT WIRE WHT/YEL WIRE YEL WIRE

AIR CONDITIONING SYSTEM AMBIENT LIGHT SENSOR SIGNAL AUTO AUTO HI BEAM ASSIST SW SIG AUTO HIGH BEAM LAMP SWITCH AUTOSAR CAN BUS (-) 2 SER BATTERY POSITIVE VOLTAGE 21 BATTERY POSITIVE VOLTAGE 22 BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/YEL WIRE BODY CONTROL MODULE COMPUTER DATA LINES SYSTEM EARLY PRODUCTION FTP GRN/BLK WIRE GRN/BRN WIRE GRN/YEL WIRE GROUND GRY/BRN WIRE HDLP SW FLASH SIG HDLP SW OFF SIGNAL HDLP SW ON SIGNAL HEAD HI BEAM SEL SW HI BEAM SIG HIGH BEAM LAMP IND HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER CONTROL MODULE INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LATE PRODUCTION LIN BUS 1 LOGIC OFF PARK PARKING BRAKE CONTROL SWITCH RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE SENSOR LOW REF SUNLOAD TEMPERATURE, AMBIENT LIGHT, SECURITY INDICATOR SENSOR TURN SIGNAL SWITCH WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL/BRN WIRE
