Cadillac CT5 I (2019-2024) transfer case fluid temperature sensor Wiring diagram

This page shows the only wiring diagram for the component.transfer case fluid temperature sensor, which is found in the car Cadillac CT5 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram transfer case fluid temperature sensor (1 of 1)

Wiring diagram transfer case fluid temperature sensor for Cadillac CT5 I (2019-2024)

Get access

BATT POSITIVE VOLTAGE BLK WIRE BLK/BLU WIRE BLU/BLK WIRE BRN/WHT WIRE BUS (+) 3 SER DATA CLTH SOL ACTR CTRL CLTH SOL ACTR LO REF COMPUTER DATA LINES SYSTEM HOT AT ALL TIMES OIL TEMP SEN SIG 2 REAR BODY WIRING HARNESS JUNCTION BLOCK RED/WHT WIRE SUMP OIL TEMP TRANSFER CASE CONTROL MODULE TRANSFER CASE FLUID TEMPERATURE SENSOR TRANSFER CASE TWO/FOUR WHEEL DRIVE CLUTCH COIL WHT WIRE YEL/BLK WIRE YEL/WHT WIRE

Go to component: -> Transfer case circuit -> TRANSFER CASE FLUID TEMPERATURE SENSOR
