Cadillac CT5 I (2019-2024) sens volt ref Wiring diagram

This page shows the only wiring diagram for the component.sens volt ref, which is found in the car Cadillac CT5 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram sens volt ref (1 of 1)

Wiring diagram sens volt ref for Cadillac CT5 I (2019-2024)

Get access

BATT POS VOLT BCM LIN BUS 8 BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GRN/WHT WIRE HOT AT ALL TIMES LOGIC MTR CLOSE CTRL MTR OPEN CTRL OBSTRUC SENS SIG 1 OBSTRUC SENS SIG 2 ORG/ WIRE PNK WIRE PPL REAR BODY WIRING HARNESS JUNCTION BLOCK RED WIRE RED/GRY WIRE ROOF CONSOLE SENS VOLT REF SLIDE SUNROOF CONTROL MODULE SUNROOF SUNSHADE MOTOR SW LOW REF TILT YEL WIRE

Go to component: -> Power top/sunroof circuit -> SENS VOLT REF
