Cadillac CT5 I (2019-2024) pvt ser data side obstacle detection can bus ser data - Wiring diagram

This page shows the only wiring diagram for the component.pvt ser data side obstacle detection can bus ser data -, which is found in the car Cadillac CT5 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram pvt ser data side obstacle detection can bus ser data - (1 of 1)

Wiring diagram pvt ser data side obstacle detection can bus ser data - for Cadillac CT5 I (2019-2024)

Get access

AUTOSAR SER DATA CAN BUS [+] 4 SER DATA BLK WIRE BLK/WHT WIRE BLU/VIO WIRE COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEMS DRIVER FRONT SIDE DOOR WINDOW CONTROL SWITCH DRIVER OUTSIDE REAR VIEW MIRROR GLASS DRIVER OUTSIDE REAR VIEW MIRROR DRIVER SIDE OBJECT DETECTION INDICATOR GRN/YEL WIRE GRY WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT SIDE OBSTACLE DETECTION CONTROL MODULE PASSENGER FRONT SIDE DOOR WINDOW SWITCH PASSENGER OUTSIDE REAR VIEW MIRROR PASSENGER OUTSIDE REAR VIEW MIRROR GLASS PASSENGER SIDE OBJECT DETECTION INDICATOR PVT SER DATA SIDE OBSTACLE DETECTION CAN BUS SER DATA + GND 21 PVT SER DATA SIDE OBSTACLE DETECTION CAN BUS SER DATA - REAR BODY WIRING HARNESS JUNCTION BLOCK RED/GRN WIRE RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE SECONDARY FUSED BATT POS VOLT 38 WHT WIRE

Go to component: -> Blind spot monitoring circuit -> PVT SER DATA SIDE OBSTACLE DETECTION CAN BUS SER DATA -
