Cadillac CT5 I (2019-2024) engine cntrl sens 5 volt ref 1 Wiring diagram

2.0L 3.0L 3.0L 2.0L ACCEL PEDAL POS SIG 1 ACCEL PEDAL POS SIG 2 ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY) ACCL PEDAL POS 5 VOLT REF 1 ACCL PEDAL POS 5 VOLT REF 2 ACCL PEDAL POS LOW REF 1 ACCL PEDAL POS LOW REF 2 AUTO START BUS (-) 2 SERIAL DATA AUTOSAR CAN BUS (+) 2 SERIAL DATA AUTOSAR CAN BUS (-) 2 SERIAL DATA GND BATT POS VOLT BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (LOWER RIGHT SIDE OF DASH) BRK APPLY SENS CTRL BRK APPLY SENS LOW REF BRK APPLY SENS SIG BRK POS SENS SIG BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE CHARGE AIR COOLER COVER CONNECTOR COMPUTER DATA LINES SYSTEM CRUISE CTRL SET/COAST/ RES/ACC SW SIG CRUISE/ETC/TCC BRAKE SIGNAL DISTANCE SENSING CRUISE CNTRL GAP UP/DOWN SW SIG ENGINE CNTRL SENS 5 VOLT REF 1 ENGINE CNTRL VEHICLE SENS LOW REF 1 ENGINE CONTROL MODULE GRN/WHT WIRE GRY/GRN WIRE HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LIGHTING CONTROL MODULE (RIGHT SIDE OF DASH) LOGIC RED WIRE RED/BLU WIRE RUN/CRANK IGN 1 VOLT STEERING WHEEL RESISTOR LADDER LOW REF THRTL ACTR CTRL CLOSE THRTL ACTR CTRL OPEN THRTL POS SENS 5 VOLT REF THRTL POS SENS LOW REF THRTL POS SENS SENT 1 SIG VIO/GRN WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/WHT WIRE
