Cadillac CT4 I (2019-2024) instrument panel wiring harness junction block Wiring diagrams

AJAR SW SIG 1 BLK WIRE BLU/GRN WIRE BLU/YEL WIRE CAN BUS (+) 2 COMPUTER DATA LINES SYSTEM DOME LIGHT ON/OFF SWITCH DOOR AJAR SWITCH GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LEFT ROOF RAIL REAR SEAT POSITION READING, COURTESY LAMP LEFT SUNSHADE LEFT SUNSHADE MIRROR LAMP LIGHTING CONTROL MODULE LIN BUS 3 LOGIC NCA WIRE PASSENGER DOOR LATCH ASSEMBLY PASSENGER DOOR SWITCH PANEL CONTROL MODULE PASSENGER WINDOW MOTOR REAR COMPARTMENT LID LATCH RED/BLU WIRE RIGHT ROOF RAIL REAR SEAT POSITION READING, COURTESY LAMP RIGHT SUNSHADE RIGHT SUNSHADE MIRROR LAMP ROOF CONSOLE VIO WIRE VIO/GRY WIRE W/O MOISTURE SENSITIVE SYSTEM, GARAGE DOOR OPENER WHT WIRE

AUTOSAR CAN BATT POS VOLT BLK WIRE BLK/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BUS (-) 5 DATA COMPUTER DATA LINES SYSTEM GRN/BLK WIRE GROUND GY USB SER DATA HEAD-UP DISPLAY HEAD-UP DISPLAY SWITCH HEADLAMP HOT AT ALL TIMES HUD HUD SIG HUD SW LOW REF HUD SW SIG INFO INSTRUMENT PANEL CLUSTER CONTROL MODULE INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LIN BUS 1 LOGIC LVDS RED/BLU WIRE YEL WIRE YEL/WHT WIRE

BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/YEL WIRE BODY CONTROL MODULE (RIGHT SIDE OF DASH) BRN/BLU WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH DAY NIGHT LED CONTROL DISTANCE SENSING CRUISE CONTROL GAP UP/DOWN SWITCH SIGNAL DRIVER INFORMATION CENTER DISPLAY ETHERNET BUS 7 (-) FORWARD COLLISION ALERT DISPLAY FORWARD COLLISION ALERT LED CONTROL FORWARD COLLISION SWITCH GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/WHT WIRE GRY/YEL WIRE HAZARD WARNING SWITCH HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT PANEL CLUSTER CONTROL MODULE INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LANE DEPARTURE WARNING DISABLE IND LANE DEPARTURE WARNING DISABLE SWITCH LANE DEPARTURE WARNING DISABLE SWITCH SIGNAL LANE DEPARTURE WARNING IND LANE DEPARTURE WARNING INDICATOR CONTROL LANE DEPARTURE WARNING SWITCH LANE KEEP ASSIST IND LOGIC REAR BODY WIRING HARNESS JUNCTION BLOCK RED/YEL WIRE STEERING WHEEL AIR BAG COIL VEHICLE AHEAD INDICATOR IND VIO/GRY WIRE WHT WIRE WHT/GRY WIRE WINDSHIELD FRONT VIEW CAMERA

BLK/BRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DISPLAY GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/YEL WIRE HOT AT ALL TIMES INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LOGIC LVDS RADIO RADIO CONTROL RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE VIO WIRE VIO/BLU WIRE VIO/YEL WIRE W/ ONSTAR W/O ONSTAR WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

AM/FM RADIO ANTENNA AMPLIFIER BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/WHT WIRE COAX COMPUTER DATA LINES SYSTEM DOWN GRN/BLK WIRE GRN/GRY WIRE GRN/YEL WIRE HOT AT ALL TIMES INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LEFT LOGIC REAR BODY WIRING HARNESS JUNCTION BLOCK RED/GRN WIRE RED/YEL WIRE RIGHT UP SEEK DOWN SEEK UP SEL STEERING WHEEL AIR BAG COIL STEERING WHEEL RADIO CONTROL SWITCH VIO WIRE VIO/BLU WIRE VIO/WHT WIRE VOL (-) YEL WIRE YEL/BLK WIRE

BLK/BRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DISPLAY GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY/YEL WIRE GY LVDS HOT AT ALL TIMES INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LOGIC LVDS RADIO RADIO CONTROL RED/BLU WIRE RED/VIO WIRE VIO WIRE VIO/YEL WIRE W/ ONSTAR W/O ONSTAR WHT/BLK WIRE

BLK/WHT WIRE BLU/BLK WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DOWN GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/GRY WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LEFT LEFT FRONT ACTIVE NOISE CANCELLATION MICROPHONE LEFT RADIO REAR SIDE DOOR SPEAKER LEFT RADIO REAR SIDE UPPER SPEAKER LEFT RADIO REAR SURROUND SPEAKER LOGIC REAR BODY WIRING HARNESS JUNCTION BLOCK RED/GRN WIRE RED/YEL WIRE RIGHT RIGHT RADIO QUARTER SPEAKER RIGHT RADIO REAR SURROUND SPEAKER SEEK DOWN SEEK UP SEL STEERING WHEEL AIR BAG COIL STEERING WHEEL RADIO CONTROL SWITCH VIO WIRE VIO/BLU WIRE VIO/WHT WIRE VOL (-) WHT WIRE WHT/BLK WIRE WHT/BRN WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE

AUTOSAR CAN BUS (+) 2 SERIAL DATA BATTERY POSITIVE VOLTAGE BLK WIRE BLK/WHT WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (RIGHT SIDE OF DASH) BRN WIRE BRN/GRY WIRE CAN BUS (+) 2 CAN BUS (-) 2 LIFTGATE AJAR SWITCH SIGNAL 1 COMPUTER DATA LINES SYSTEM DISPLAY DRIVER FRONT SIDE DOOR WINDOW CONTROL SWITCH GRN/BLK WIRE GRN/YEL WIRE GROUND HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK INTERIOR REAR COMPARTMENT LID RELEASE SWITCH LIFTGATE WINDOW/REAR COMPT LID UNLATCH SIGNAL LIGHTING CONTROL MODULE LIN BUS 2 LIN BUS 3 LOGIC MULTI-FUNCTION CARRIER REAR LICENSE PLATE LAMP REAR CLOSURE HANDLE SWITCH OPEN SIGNAL REAR CLOSURE UNLATCH ACTUATOR UNLATCH CONTROL REAR COMPARTMENT LID LATCH RED WIRE RED/BRN WIRE VIO/BLU WIRE VIO/GRY WIRE W/ WINDSHIELD HEAD-UP DISPLAY W/O WINDSHIELD HEAD-UP DISPLAY WHT WIRE YEL/BLU WIRE

BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BUS (-) SERIAL DATA COMPUTER DATA LINES SYSTEM CTRL VLV 1 CTRL VLV 2 DRIVER INFORMATION CENTER DISPLAY ECT IND ELECTRONIC MUFFLERS SYSTEM ENGINE OIL IND EVAP VENT SOL FEEDBACK SIG FUEL GAUGE FUEL IND FUEL PRESSURE FUEL PRESSURE SENS FUEL PUMP ASSEMBLY FUEL PUMP CTRL FUEL PUMP POWER CONTROL MODULE FUEL PUMP PRIMARY FUEL PUMP SUPPLY FUEL TANK FUEL TANK PRESSURE FUSED BATT GRN WIRE GRN/BLK WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/YEL WIRE HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT CLUSTER INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LEVEL SENS SIG LOGIC MALFUNCTION IND NCA WIRE PHASE 3 POSITIVE VOLTAGE 26 POWER MODULE POWERTRAIN CAN PRESSURE SENS SIG PRIMARY FUEL PRIVATE SERIAL DATA RED/VIO WIRE RELAY CTRL SECONDARY SECONDARY FUEL SENS 2 LO REF SENS LO REF SENS LOW REF SENS SIG SHIELD GND SUPPLY VOLTAGE VALVE CTRL VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/GRY WIRE VOLTAGE PHASE 2 W/O WINDSHIELD HEAD-UP DISPLAY WAKE UP SIG WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE

BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLU WIRE ENGINE CONTROLS IGNITION RELAY ENGINE COOLANT BYPASS VALVE ENGINE COOLANT FLOW CONTROL VALVE (REAR OF GENERATOR) ENGINE COOLANT TEMPERATURE SENSOR 1 ENGINE WIRING HARNESS JUNCTION BLOCK EXHAUST CAMSHAFT PROFILE SLEEVE POSITION SENSOR 1 EXHAUST CAMSHAFT PROFILE SLEEVE POSITION SENSOR 2 FUEL PRESSURE, TEMPERATURE SENSOR GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK INTAKE CAMSHAFT PROFILE SLEEVE POSITION SENSOR 1 INTAKE CAMSHAFT PROFILE SLEEVE POSITION SENSOR 2 LOGIC ORG/GRN WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/VIO WIRE YEL/WHT WIRE
