Cadillac CT4 I (2019-2024) ground 27 Wiring diagram
This page shows the only wiring diagram for the component.ground 27, which is found in the car Cadillac CT4 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground 27 (1 of 1)
AUTOSAR CAN BUS (+) 1 SERIAL DATA
AUTOSAR CAN BUS (+) 2 SERIAL DATA
BATTERY DISTRIBUTION ENGINE COMPARTMENT FUSE BLOCK
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BRAKE FLUID LEVEL SENSOR
BRAKE FLUID LEVEL SWITCH SIGNAL
BRAKE MASTER CYLINDER)
BRAKE SYSTEM CONTROL MODULE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC BRAKE CONTROL MODULE LIN BUS 1
ENGINE WIRING HARNESS JUNCTION BLOCK
FRONT BRAKE PAD WEAR SENSOR SIGNAL
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GROUND 27
GROUND 7
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT WHEEL SPEED SENSOR
LEFT FRONT WHEEL SPEED SENSOR CONTROL
LEFT FRONT WHEEL SPEED SENSOR SIGNAL
LEFT PARK BRAKE MOTOR APPLY CONTROL
LEFT PARK BRAKE MOTOR LOW REFERENCE
LEFT PARKING BRAKE ACTUATOR
LEFT REAR WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR CONTROL
LEFT REAR WHEEL SPEED SENSOR SIGNAL
NCA WIRE
REAR BRAKE PAD WEAR SENSOR SIGNAL
RED/BRN WIRE
RED/WHT WIRE
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT FRONT WHEEL SPEED SENSOR CONTROL
RIGHT FRONT WHEEL SPEED SENSOR SIGNAL
RIGHT PARK BRAKE MOTOR APPLY CONTROL
RIGHT PARK BRAKE MOTOR LOW REFERENCE
RIGHT PARKING BRAKE ACTUATOR
RIGHT REAR WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR CONTROL
RIGHT REAR WHEEL SPEED SENSOR SIGNAL
RUN/CRANK IGNITION 1 VOLTAGE 21
SECONDARY FUSED BATTERY POSITIVE VOLTAGE 10
SECONDARY FUSED BATTERY POSITIVE VOLTAGE 11
VIO WIRE
VIO/BLK WIRE
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> GROUND 27
