Car Wiring Diagrams for Trunk release circuit for Cadillac CT4-V I (2019-2024)

AUTOSAR CAN BUS (+) 2 SERIAL DATA BATTERY POSITIVE VOLTAGE BLK WIRE BLK/WHT WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (RIGHT SIDE OF DASH) BRN WIRE BRN/GRY WIRE CAN BUS (+) 2 CAN BUS (-) 2 LIFTGATE AJAR SWITCH SIGNAL 1 COMPUTER DATA LINES SYSTEM DISPLAY DRIVER FRONT SIDE DOOR WINDOW CONTROL SWITCH GRN/BLK WIRE GRN/YEL WIRE GROUND HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK INTERIOR REAR COMPARTMENT LID RELEASE SWITCH LIFTGATE WINDOW/REAR COMPT LID UNLATCH SIGNAL LIGHTING CONTROL MODULE LIN BUS 2 LIN BUS 3 LOGIC MULTI-FUNCTION CARRIER REAR LICENSE PLATE LAMP REAR CLOSURE HANDLE SWITCH OPEN SIGNAL REAR CLOSURE UNLATCH ACTUATOR UNLATCH CONTROL REAR COMPARTMENT LID LATCH RED WIRE RED/BRN WIRE VIO/BLU WIRE VIO/GRY WIRE W/ WINDSHIELD HEAD-UP DISPLAY W/O WINDSHIELD HEAD-UP DISPLAY WHT WIRE YEL/BLU WIRE
