Cadillac CT4-V I (2019-2024) windshield wiper switch high sig Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper switch high sig, which is found in the car Cadillac CT4-V I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper switch high sig (1 of 1)
BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/GRN WIRE
BRN/GRY WIRE
FRONT TURN SIG LAMP FEEDBACK SIG
GRN WIRE
GRN/VIO WIRE
GRY WIRE
HEADLIGHTS SYSTEM
LEFT CORNERING LAMP CONTROL
LEFT FRONT LAMP ASSEMBLY CONTROL LEFT FRONT DRL CONTROL
LEFT FRONT PARK LAMP
LEFT FRONT PARK LAMP CONTROL
LEFT FRONT PARK LAMP CONTROL LEFT FRONT DRL CONTROL
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP CONTROL
LEFT HEADLAMP HI BEAM CONTROL
LEFT HEADLAMP HIGH BEAM CONTROL
LEFT HEADLAMP LOW BEAM CONTROL
LIGHTING CONTROL MODULE (RIGHT SIDE OF DASH)
LOGIC
LOW WASHER FLUID INDICATOR CTRL
NCA WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RF TURN SIG LAMP FEEDBACK SIG
RIGHT CORNERING LAMP
RIGHT FRONT PARK LAMP
RIGHT FRONT PARK LAMP CONTROL
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT PARK DAYTIME RUNNING LAMP
RIGHT TURN SIGNAL LAMP
SEC FUSED BATT POSITIVE VOLT 55
SEC FUSED BATT POSITIVE VOLT 56
SECONDARY FUSED BATT POS VOLT 57
VIO WIRE
VIO/BLK WIRE
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
WINDSHIELD WASHER RELAY CONTROL
WINDSHIELD WIPER MOTOR PARK SW SIG
WINDSHIELD WIPER MOTOR RLY COIL CTRL
WINDSHIELD WIPER SWITCH HIGH SIG
WIPER/WASHER SYSTEM
YEL WIRE
YEL/GRY WIRE
YEL/WHT WIRE
Go to component: -> Exterior lamps circuit (4 of 4) -> WINDSHIELD WIPER SWITCH HIGH SIG
