Cadillac CT4-V I (2019-2024) transmission intermediate speed sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.transmission intermediate speed sensor 2, which is found in the car Cadillac CT4-V I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission intermediate speed sensor 2 (1 of 1)
ADAPTIVE CRUISE IND
ADAPTIVE CRUISE SWITCH
AUTOMATIC TRANSMISSION ASSEMBLY (10 SPEED A/T)
AUTOMATIC TRANSMISSION ASSEMBLY (8 SPEED A/T)
AUTOSAR
AUTOSAR CAN BUS (+) 2 SERIAL DATA
BATT POS
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CAN-BUS
CANCEL SWITCH
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
CRUISE IND
DATA SERIAL
DRIVER INFORMATION CENTER DISPLAY
GRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/GRN WIRE
INPUT SPD SIG
INSTRUMENT PANEL CLUSTER CONTROL MODULE
LOGIC
NCA WIRE
RED WIRE
RED/BLU WIRE
RES+
SEATS SYSTEM
SET-
STEERING WHEEL AIR BAG COIL
TRANS INPUT SPD SENS SIG
TRANS INTERMEDIATE SPD SIG
TRANS OUT SPD SENS SIG
TRANSMISSION CONTROL MODULE
TRANSMISSION INPUT SHAFT SPEED SENSOR
TRANSMISSION INTERMEDIATE SHAFT SPEED SENSOR
TRANSMISSION INTERMEDIATE SPEED SENSOR 1
TRANSMISSION INTERMEDIATE SPEED SENSOR 2
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
VIO WIRE
VIO/WHT WIRE
VOLT 32
W/O WINDSHIELD HEAD-UP DISPLAY
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component: -> Cruise control circuit (2 of 2) -> TRANSMISSION INTERMEDIATE SPEED SENSOR 2
