Cadillac CT4-V I (2019-2024) steering wheel heating volt ref Wiring diagram
This page shows the only wiring diagram for the component.steering wheel heating volt ref, which is found in the car Cadillac CT4-V I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel heating volt ref (1 of 1)
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CTRL MODULE LIN BUS 12
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
GRN/BLK WIRE
HEATED STEERING WHEEL IND
HEATED STEERING WHEEL MODULE
HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
INDICATOR DIMMING CONTROL
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LOGIC
NCA WIRE
RED/BRN WIRE
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATER
STEERING WHEEL HEATING HIGH CTRL
STEERING WHEEL HEATING SW LED CTRL
STEERING WHEEL HEATING SW SIG
STEERING WHEEL HEATING VOLT REF
STEERING WHEEL RADIO CONTROL SWITCH
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/YEL WIRE
YEL/GRY WIRE
Go to component: -> Heated steering wheel circuit -> STEERING WHEEL HEATING VOLT REF
