Cadillac CT4-V I (2019-2024) right headlamp high beam control Wiring diagram
This page shows the only wiring diagram for the component.right headlamp high beam control, which is found in the car Cadillac CT4-V I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right headlamp high beam control (1 of 1)
AUTOSAR CAN BUS (+) 2 SERIAL DATA
BLK/WHT WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
CRUISE/ETC/TCC BRAKE SIGNAL
GRN/VIO WIRE
GROUND 22
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL FUSE BLOCK
LIFTGATE AJAR SWITCH SIGNAL 1
LIGHTING CONTROL MODULE (RIGHT SIDE OF DASH)
REAR BODY FUSE BLOCK
RED/BLU WIRE
RED/BRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RF LAMP ASSEMBLY CONTROL
RF TURN SIGNAL LAMP CONTROL
RIGHT CORNERING LAMP CONTROL
RIGHT FRONT DRL CONTROL
RIGHT FRONT PARK LAMP CONTROL
RIGHT HEADLAMP HIGH BEAM CONTROL
RIGHT HEADLAMP LOW BEAM CONTROL
SEC FUSED BATTERY POSITIVE VOLT 17
SEC FUSED BATTERY POSITIVE VOLT 27
SEC FUSED BATTERY POSITIVE VOLT 28
SEC FUSED BATTERY POSITIVE VOLT 29
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNDERHOOD FUSE BLOCK
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Exterior lamps circuit (2 of 4) -> RIGHT HEADLAMP HIGH BEAM CONTROL
