Cadillac CT4-V I (2019-2024) left side object detection led control wiring diagram
This page shows the only wiring diagram for the component.left side object detection led control, which is found in the car Cadillac CT4-V I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left side object detection led control wiring diagram (1 of 1)
AUTOSAR SERIAL DATA CAN BUS (-) 4
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLU/VIO WIRE
BODY CONTROL MODULE LIN BUS 3
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SIDE DOOR WINDOW CONTROL SWITCH
DRIVER OUTSIDE REAR VIEW MIRROR GLASS DRIVER OUTSIDE REAR VIEW MIRROR
DRIVER SIDE OBJECT DETECTION INDICATOR
GRN/YEL WIRE
GROUND
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT SIDE OBJECT DETECTION LED CONTROL
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (LEFT SIDE OF REAR FASCIA)
NCA WIRE
PASSENGER FRONT SIDE DOOR WINDOW SWITCH
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
PASSENGER SIDE OBJECT DETECTION INDICATOR
PRIVATE SERIAL DATA SIDE OBSTACLE DETECTION CAN BUS (-) SERIAL DATA
REAR BODY WIRING HARNESS JUNCTION BLOCK
RED/GRN WIRE
RIGHT SIDE OBJECT DETECTION LED CONTROL
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (RIGHT SIDE OF REAR FASCIA)
WHT WIRE
Go to component -> Blind spot monitoring circuit -> LEFT SIDE OBJECT DETECTION LED CONTROL
