Cadillac CT4-V I (2019-2024) forward collision switch Wiring diagram
This page shows the only wiring diagram for the component.forward collision switch, which is found in the car Cadillac CT4-V I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram forward collision switch (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (RIGHT SIDE OF DASH)
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
DAY NIGHT LED CONTROL
DISTANCE SENSING CRUISE CONTROL GAP UP/DOWN SWITCH SIGNAL
DRIVER INFORMATION CENTER DISPLAY
ETHERNET BUS 7 (-)
FORWARD COLLISION ALERT DISPLAY
FORWARD COLLISION ALERT LED CONTROL
FORWARD COLLISION SWITCH
GRY/BLK WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HAZARD WARNING SWITCH
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER CONTROL MODULE
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LANE DEPARTURE WARNING DISABLE IND
LANE DEPARTURE WARNING DISABLE SWITCH
LANE DEPARTURE WARNING DISABLE SWITCH SIGNAL
LANE DEPARTURE WARNING IND
LANE DEPARTURE WARNING INDICATOR CONTROL
LANE DEPARTURE WARNING SWITCH
LANE KEEP ASSIST IND
LOGIC
REAR BODY WIRING HARNESS JUNCTION BLOCK
RED/YEL WIRE
STEERING WHEEL AIR BAG COIL
VEHICLE AHEAD INDICATOR IND
VIO/GRY WIRE
WHT WIRE
WHT/GRY WIRE
WINDSHIELD FRONT VIEW CAMERA
Go to component: -> Lane departure warning circuit -> FORWARD COLLISION SWITCH
